Home / Products / Proximity Sensor / Pepperl Fuchs / NBN12-18GM50-E2-V1
Pepperl Fuchs Proximity Sensor
NBN12-18GM50-E2-V1
Challaturu has the ideal solution for your inductive proximity switching needs with the Pepperl Fuchs NBN12-18GM50-E2-V1. This non-flush type switch features an 8mm sensing range, PNP configuration, NO switching function, and 3-wire output.
NBN12-18GM50-E2-V1 Technical Specifications:
| Switching function | Normally open (NO) | |
| Output type | PNP | |
| Rated operating distance | 12 mm | |
| Installation | non-flush | |
| Output polarity | DC | |
| Output Type | 3-wire | |
| Operating voltage | 5 … 60 V | |
| Switching frequency | 0 … 1300 Hz | |
| Operating current | 0 … 200 mA | |
| Switching state indicator | Multihole-LED, yellow | |
| Ambient temperature | -40 … 85 °C (-40 … 185 °F) | |
| Connection type | Connector plug | |
| Housing material | brass, white bronze coated | |
| Threading | M12 x 1 | |
| Number of pins | 3 | |
| Sensing face | PBT, green | |
| Degree of protection | IP68 | |
Product Documentation: NBN12-18GM50-E2-V1
Related Products: NBN12-18GM50-E2-V1
NBB5-18GM50-E2-V1
Inductive Proximity Sensor, Sensor diameter: M18, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 1950 Hz, Output type: 3-wire, Construction type: Cylindrical thread, Rated operating distance: 5 mm, Type of voltage: DC, Connection type: Connector plug, Operating voltage: DC 5-36V, Housing material: Brass, white bronze coated, Sensing face: PBT, green, Degree of protection: IP68.
NBB5-18GM40-Z0
Inductive Proximity Sensor, Sensor diameter: M18, Rated operating distance: 5 mm, Switching function: Normally open (NO), Output type: Two-wire, Installation: Flush, Switching frequency: 0 … 500 Hz, Output type: 2-wire, Type of voltage: DC, Connection type: 2 m PVC cable, Operating voltage: 5 … 60 V, Housing material: Brass with nickel-plating, Degree of protection: IP67.
NBN4-12GM50-E2-V1
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 4 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 2650 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB0 6-3M22-E2
Inductive Proximity Sensor, Sensor diameter: 0.6mm, Rated operating distance: 0.6 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 1400 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 10 … 30 V, Housing material: Stainless steel 1.4305 / AISI 303, Degree of protection: IP67.
NBB1 5-F79-E2
Inductive Proximity Sensor, Sensor diameter: Not specified, Rated operating distance: 1.5 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 1200 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Flexible leads, Operating voltage: 5 … 30 V DC, Housing material: PA, Degree of protection: IP67.
NBB4-12GM50-E0
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 4 mm, Switching function: Normally open (NO), Output type: NPN, Installation: Flush, Switching frequency: 0 … 2550 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68, Cable length: 2 m.
NBB4-12GM50-E2
Inductive Proximity Sensor, Sensor diameter: M12, Switching function: Normally open (NO), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 2550 Hz, Output type: 3-wire, Construction type: Cylindrical thread, Sensor length: 50mm, Type of voltage: DC, Connection type: 2 m PVC cable, Operating voltage: DC 10-30V, Housing material: PBT, Degree of protection: IP68
NBN8-12GM50-E2
Inductive Proximity Sensor, Sensor diameter: M12, Switching function: Normally open (NO), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 1650 Hz, Output type: 3-wire, Sensor length: 50mm, Type of voltage: DC, Connection type: 2 m PVC cable, Operating voltage: DC 5-36V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB2-12GM50-E2-V1
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 2 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 3500 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB2-8GM25-E3-V3
Inductive Proximity Sensor, Sensor diameter: M8, Rated operating distance: 2 mm, Switching function: Normally closed (NC), Output type: PNP, Installation: Flush, Switching frequency: 0 … 6000 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug M8 x 1, Operating voltage: 5 … 30 V, Housing material: Brass with nickel-plating, Degree of protection: IP67.
NBB2-8GM40-A2-V1
Inductive Proximity Sensor, Sensor diameter: M8, Rated operating distance: 2 mm, Switching function: complementary, Output type: PNP, Installation: Flush, Switching frequency: 0 … 6000 Hz, Output type: 4-wire, Type of voltage: DC, Connection type: Connector plug M12 x 1 , 4-pin, Operating voltage: 5 … 30 V, Housing material: Brass, nickel-plated, Degree of protection: IP67.
NBB4-12GM30-E0-V1
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 4 mm, Switching function: Normally open (NO), Output type: NPN, Installation: Flush, Switching frequency: 0 … 2550 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB2-12GM50-E2-V1
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 2 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 3500 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB15-30GM50-E2-M
Inductive Proximity Sensor, Sensor diameter: M30, Rated operating distance: 15 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 600 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 60 V, Housing material: Brass with nickel-plating, Degree of protection: IP68/IP69K.
NBB4-12GM50-E3-V1
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 4 mm, Switching function: Normally closed (NC), Output type: PNP, Installation: Flush, Switching frequency: 0 … 2550 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
If you are looking for an ideal solution for your Inductive & Capacitive sensor needs with the Pepperl Fuchs NBN12-18GM50-E2-V1 sensor, Challaturu is the way to go. This sensor has a non-flush installation type with an 8mm sensing range and a normally open (NO) switching function. Additionally, it features a PNP configuration, and a 3-wire output, and operates on DC output polarity with an operating voltage range of 5 to 60V.
The switching frequency of this sensor ranges from 0 to 1300 Hz and it can handle an operating current of 0 to 200 mA. It has a multihole-LED yellow switching state indicator that makes it easy to detect the switching state. Moreover, the sensor is constructed with brass, nickel-plated housing material, and a PBT sensing face, which provides excellent protection against harsh environments.
This sensor also has a high degree of protection with an IP68, which means it is well-protected against dust and water. The ambient temperature range of this sensor is -40 to 85 °C (-40 to 185 °F), making it suitable for use in extreme temperatures. Lastly, it is easy to install with a 3-pin connector plug M12 x 1. In conclusion, Challaturu is the ideal solution for your inductive proximity switching needs with the Pepperl Fuchs NBN12-18GM50-E2-V1 sensor.
You can check P&F 12mm series with Connector type.
