Pepperl Fuchs Inductive Sensor NBN4-12GM50-E2-V1
Here are the technical specifications of Pepperl+Fuchs NBN4-12GM50-E2-V1
- M12 Diameter
- Sensing Distance: 4mm
- Installation Type: Non-Flush
- Output: PNP with 3 wires
- Switching function: Normally Open (NO)
- Sensor length: 50mm
- Operating voltage: DC 10-30V
- Electrical connection: M12 Connector Type
₹850.00
In stock
NBN4-12GM50-E2-V1 Technical Specifications:
Pepperl+Fuchs NBN4 12GM50 E2 V1 inductive sensor is designed for automation applications and features a normally open (NO) switching function with a PNP output type and a 3-wire connection. It has a rated operating distance of 4 mm and is designed for Non-flush installation. The sensor operates on a DC output polarity with an operating voltage range of 10 to 30 V.
| Switching function | Normally open (NO) | |
| Output type | PNP | |
| Rated operating distance | 4 mm | |
| Installation | non-flush | |
| Output polarity | DC | |
| Assured operating distance | 0 … 3.24 mm | |
| Reduction factor rAl | 0.5 | |
| Reduction factor rCu | 0.4 | |
| Reduction factor r304 | 0.8 | |
| Hysteresis | Typ. 5% | |
| Operating voltage | 10 … 30 V | |
| Switching frequency | 0 … 1200 Hz | |
| Reverse polarity protection | reverse polarity protected | |
| Short-circuit protection | pulsing | |
| Voltage drop | ≤ 3 V | |
| Repeat accuracy | ≤ 0.01 mm | |
| Operating current | 0 … 200 mA | |
| Off-state current | 0 … 0.5 mA typ. 0.1 µA at 25 °C | |
| No-load supply current | ≤ 17 mA | |
| Switching state indicator | Multihole-LED, yellow | |
| Connection type | Connector M12 x 1, 4-pin | |
| Housing material | brass, nickel-plated | |
| Sensing face | PBT | |
| Housing diameter | 12 mm | |
| Degree of protection | IP67 | |
| Mission Time (TM) | 20 a | |
| Diagnostic Coverage (DC) | 0 % | |
Product Documentation: NBN4-12GM50-E2-V1
Here is the main technical specification of Pepperl Fuchs Inductive Proximity Sensor NBB5-18GM50 E2 V1: M12 Dia, Non-Flush, PNP, 4mm Sensing, Normally Open, Connector type.
