Pepperl + Fuchs Inductive Proximity Sensors NBN40-U1-E2
The technical specifications for the NBN40-U1-E2 are as follows:
- Switching function: Normally Open (NO)
- Output type: PNP
- Rated operating distance: 40mm
- Installation: Non-flush
- Output polarity: DC
- Output type: 3-wire
- Operating voltage range: 10 to 30 VDC
- Switching frequency range: 0 to 180Hz
NBN40-U1-E2 Technical Specifications :
| Switching function | Normally open (NO) |
| Output type | PNP |
| Rated operating distance | 40 mm |
| Installation | non-flush |
| Output polarity | DC |
| Assured operating distance | 0 … 32.4 mm |
| Actual operating distance | 36 … 44 mm |
| Reduction factor rAl | 0.31 |
| Reduction factor rCu | 0.3 |
| Reduction factor r304 | 0.74 |
| Reduction factor rBrass | 0.39 |
| Output type | 3-wire |
| Operating voltage | 10 … 30 V DC |
| Switching frequency | 0 … 180 Hz |
| Hysteresis | typ. 5 % |
| Reverse polarity protection | reverse polarity protected |
| Short-circuit protection | pulsing |
| Voltage drop | ≤ 2 V |
| No-load supply current | ≤ 20 mA |
| Operating current | 0 … 200 mA |
| Operating voltage indicator | LED, green |
| Off-state current | 0 … 0.5 mA typ. 0.01 mA |
| Time delay before availability | 80 ms |
| Switching state indicator | LED, yellow |
| MTTFd | 1510 a |
| Mission Time (TM) | 20 a |
| Diagnostic Coverage (DC) | 0% |
| Standard conformity-Standards | EN 60947-5-2:2007 EN 60947-5-2/A1:2012 IEC 60947-5-2:2007 IEC 60947-5-2 AMD 1:2012 |
| UL approval | cULus Listed, General Purpose |
| CCC approval | CCC approval / marking not required for products rated ≤36 V |
| EAC conformity | TR CU 020/2011 |
| Connection type | screw terminals |
| Information for connection | A maximum of two conductors with the same core cross section may be mounted on one terminal connection! tightening torque 1.2 Nm + 10 % |
| Core cross-section | up to 2.5 mm2 |
| Minimum core cross-section | without wire end ferrule 0.5 mm2 , with connector sleeves 0.34 mm2 |
| Maximum core cross-section | without wire end ferrule 2.5 mm2 , with connector sleeves 1.5 mm2 |
| Housing material | PA/metal with epoxy powder coating |
| Sensing face | PA |
| Housing base | plastic |
| Degree of protection | IP68 / IP69K |
| Mass | 225 g |
| Note | Tightening torque: 1.8 Nm (housing) |
