Pepperl Fuchs Inductive Sensor
NBN8-12GM50-A2-V1
NBN8-12GM50-A2-V1- Technical Specifications:
If you are in search of an Inductive Proximity Switch with an 8mm sensing range, PNP output, non-flush type, complementary switching function, and a connection type sensor, then the P&F NBN8-12GM50-A2-V1 is the ideal solution for your needs, conveniently available at Challaturu Automation.
| Switching function | complementary | |
| Output type | PNP | |
| Rated operating distance | 8 mm | |
| Installation | Non-flush | |
| Output Type | 3-wire | |
| Output polarity | DC | |
| Operating voltage | 7 … 30 V | |
| Switching frequency | 0 … 1200 Hz | |
| Switching state indicator | Multihole-LED, yellow | |
| Ambient temperature | -40 … 85 °C (-40 … 185 °F) | |
| Connection type | Connector plug | |
| Housing material | brass, white bronze coated | |
| Sensing face | PBT, Green | |
| Degree of protection | IP68 | |
| Threading | M12 x 1 | |
| Number of pins | 4 | |
Product Documentation: NBN8-12GM50-A2-V1
Related Products: NBN8-12GM50-A2-V1
NBN8-12GM50-E2
Inductive Proximity Sensor, Sensor diameter: M12, Switching function: Normally open (NO), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 1650 Hz, Output type: 3-wire, Sensor length: 50mm, Type of voltage: DC, Connection type: 2 m PVC cable, Operating voltage: DC 5-36V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBN8-18GM50-E2-V1
Inductive Proximity Sensor, Sensor diameter: M18, Rated operating distance: 8 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 1650 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBN8-18GM50-E2
Inductive Proximity Sensor, Sensor diameter: M18, Rated operating distance: 8 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 1650 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB10-30GM40-Z0-V1
Inductive Proximity Sensor, Sensor diameter: M30, Rated operating distance: 10 mm, Switching function: Normally open (NO), Output type: Two-wire, Installation: Flush, Switching frequency: 0 … 150 Hz, Output type: 2-wire, Type of voltage: DC, Connection type: Connector plug M12 x 1 , 4-pin, Operating voltage: 5 … 60 V, Housing material: Brass with nickel-plated, Degree of protection: IP67.
NBB10-30GM50-E0
Inductive Proximity Sensor, Sensor diameter: M30, Rated operating distance: 10 mm, Switching function: Normally open (NO), Output type: NPN, Installation: Flush, Switching frequency: 0 … 1100 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB10-30GM50-E2
Inductive Proximity Sensor, Sensor diameter: M30, Rated operating distance: 10 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 1100 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB10-30GM50-E2-C-V1
Inductive Proximity Sensor Rated operating distance: 10 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 10 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug M12 x 1, Operating voltage: 10 … 30 V DC, Housing material: Brass with PTFE coating, Degree of protection: IP67.
NBB10-30GM50-E2-V1
Inductive Proximity Sensor, Sensor diameter: M30, Rated operating distance: 10 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 1100 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB10-30GM50-WS
Inductive Proximity Sensor, Sensor diameter: M30, Rated operating distance: 10 mm, Switching function: Normally open (NO), Output type: Two-wire, Installation: Flush, Switching frequency: 0 … 20 Hz, Type of voltage: AC, Connection type: Cable, Operating voltage: 20 … 253 V, Housing material: Brass with nickel-plating, Degree of protection: IP67.
NBB10-30GM60-A2-V1
Inductive Proximity Sensor, Sensor diameter: M30, Rated operating distance: 10 mm, Switching function: Complementary, Output type: PNP, Installation: Flush, Switching frequency: 0 … 1100 Hz, Output type: 4-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB15-30GM30-E2-V1
Inductive Proximity Sensor, Sensor diameter: M30, Rated operating distance: 15 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 550 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB15-30GM50-A2-V1
Inductive Proximity Sensor, Sensor diameter: M30, Rated operating distance: 15 mm, Switching function: Complementary, Output type: PNP, Installation: Flush, Switching frequency: 0 … 550 Hz, Output type: 4-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB15-30GM50-E0
Inductive Proximity Sensor, Sensor diameter: M30, Rated operating distance: 15 mm, Switching function: Normally open (NO), Output type: NPN, Installation: Flush, Switching frequency: 0 … 550 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB5-18GM40-Z0
Inductive Proximity Sensor, Sensor diameter: M18, Rated operating distance: 5 mm, Switching function: Normally open (NO), Output type: Two-wire, Installation: Flush, Switching frequency: 0 … 500 Hz, Output type: 2-wire, Type of voltage: DC, Connection type: 2 m PVC cable, Operating voltage: 5 … 60 V, Housing material: Brass with nickel-plating, Degree of protection: IP67.
NBB5-18GM50-E2
Inductive Proximity Sensor, Sensor diameter: M18, Rated operating distance: 5 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 1950 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
Challaturu Automation can offer you the P&F NBN8-12GM50-A2-V1 Inductive and Capacitive Sensors that could be an ideal solution for your needs if you require a non-flush type sensor with PNP output, complementary switching function, and a connection type sensor.
This sensor has a rated operating distance of 8mm and operates with a 3-wire output type with DC output polarity. It can operate at a voltage range of 7 to 30 volts and can switch at frequencies up to 1200 Hz. The sensor also features a multihole-LED yellow switching state indicator for easy monitoring of the switching state.
The Pepperl Fuchs Inductive Sensor has a connector plug M12 x 1 with four pins for easy installation. The housing of the sensor is made of nickel-plated brass, and the sensing face is made of PBT. The sensor is rated IP68 / IP69K for its degree of protection, making it dust-tight and waterproof against high-pressure water jets.
Overall, if you require an Inductive Switch with the specific technical specifications mentioned above, the P&F NB8-12GM50-A2-V1 could be the ideal solution for your needs. You can conveniently purchase this sensor at Challaturu Automation.
You can check the P&F 8mm series with the Connector type.
