Pepperl Fuchs Inductive Sensors NBN8-12GM50-E2
The Pepperl+Fuchs NBN8-12GM50-E2 technical specifications are:
- Sensor diameter: M12
- Sensing distance: 8mm
- Installation type: Non-flush
- Output: PNP with 3 wire
- Switching function: Normally Open (NO)
- Sensor length: 50mm
- Operating voltage: DC 10-30V
- Electrical connection: Cable type.
Original price was: ₹950.00.₹700.00Current price is: ₹700.00.
In stock
NBN8-12GM50-E2 Technical Specifications:
| Switching function | Normally open (NO) | |
| Output type | PNP | |
| Rated operating distance | 8 mm | |
| Installation | non-flush | |
| Output polarity | DC | |
| Assured operating distance | 0 … 6.48 mm | |
| Reduction factor rAl | 0.39 | |
| Reduction factor rCu | 0.3 | |
| Reduction factor r304 | 0.7 | |
| Reduction factor rBrass | 0.45 | |
| Output type | 3-wire | |
| Operating voltage | 10 … 30 V | |
| Switching frequency | 0 … 1500 Hz | |
| Hysteresis | Typ. 5% | |
| Reverse polarity protection | reverse polarity protected | |
| Short-circuit protection | pulsing | |
| Voltage drop | ≤ 3 V | |
| Operating current | 0 … 200 mA | |
| Off-state current | 0 … 0.5 mA typ. 0.1 µA at 25 °C | |
| No-load supply current | ≤ 16 mA | |
| Switching state indicator | all direction LED, yellow | |
| Ambient temperature | -25 … 70 °C (-13 … 158 °F) | |
| Connection type | cable PVC, 2 m | |
| Core cross-section | 0.14 mm2 | |
| Housing material | brass, nickel-plated | |
| Sensing face | PBT | |
| Degree of protection | IP67 | |
| Mission Time (TM) | 20 a | |
Product Documentation: NBN8-12GM50-E2
Here is the main technical specification of Pepperl Fuchs Inductive Proximity Sensor NBB5-18GM50 E2 V1: M12 Dia, Non-Flush, PNP, 8mm Sensing, Normally Open, Cable type.
If you want to know all range Pepperl Fuchs proximity models you can check.
