Pepperl Fuchs Proximity Switch NEN40-30GM60-E2-V1
NEN40-30GM60-E2-V1 Technical Specifications:
If you require a proximity switch from P&F with a 10mm Rated operating distance, PNP output, non-flush Installation, and NO switching function, the Pepperl Fuchs NEN40-30GM60-E2-V1 is available at IndMALL Automation. This sensor provides the perfect solution for your needs.
| Switching function | Normally open (NO) | |
| Output type | PNP | |
| Rated operating distance | 40 mm | |
| Installation | Non-flush | |
| Output Type | 3-wire | |
| Output polarity | DC | |
| Operating voltage | 10 … 30 V | |
| Switching frequency | 0 … 100 Hz | |
| Switching state indicator | LED, yellow | |
| Ambient temperature | -25 … 70 °C (-13 … 158 °F) | |
| Connection type | Connector plug M12 x 1 , 4-pin | |
| Housing material | chromium plated brass | |
| Sensing face | PBT | |
| Degree of protection | IP67 | |
Product Documentation: NEN40-30GM60-E2-V1
Related Products: NEN40-30GM60-E2-V1
NBB10-30GM60-A2-V1
Inductive Proximity Sensor, Sensor diameter: M30, Rated operating distance: 10 mm, Switching function: Complementary, Output type: PNP, Installation: Flush, Switching frequency: 0 … 1100 Hz, Output type: 4-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB15-30GM30-E2-V1
Inductive Proximity Sensor, Sensor diameter: M30, Rated operating distance: 15 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 550 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB15-30GM50-A2-V1
Inductive Proximity Sensor, Sensor diameter: M30, Rated operating distance: 15 mm, Switching function: Complementary, Output type: PNP, Installation: Flush, Switching frequency: 0 … 550 Hz, Output type: 4-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB15-30GM50-E0
Inductive Proximity Sensor, Sensor diameter: M30, Rated operating distance: 15 mm, Switching function: Normally open (NO), Output type: NPN, Installation: Flush, Switching frequency: 0 … 550 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB4-12GM50-E2
Inductive Proximity Sensor, Sensor diameter: M12, Switching function: Normally open (NO), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 2550 Hz, Output type: 3-wire, Construction type: Cylindrical thread, Sensor length: 50mm, Type of voltage: DC, Connection type: 2 m PVC cable, Operating voltage: DC 10-30V, Housing material: PBT, Degree of protection: IP68
NBN8-12GM50-E2
Inductive Proximity Sensor, Sensor diameter: M12, Switching function: Normally open (NO), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 1650 Hz, Output type: 3-wire, Sensor length: 50mm, Type of voltage: DC, Connection type: 2 m PVC cable, Operating voltage: DC 5-36V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBN8-18GM50-E2-V1
Inductive Proximity Sensor, Sensor diameter: M18, Rated operating distance: 8 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 1650 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBN8-18GM50-E2
Inductive Proximity Sensor, Sensor diameter: M18, Rated operating distance: 8 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 1650 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB5-18GM40-Z0
Inductive Proximity Sensor, Sensor diameter: M18, Rated operating distance: 5 mm, Switching function: Normally open (NO), Output type: Two-wire, Installation: Flush, Switching frequency: 0 … 500 Hz, Output type: 2-wire, Type of voltage: DC, Connection type: 2 m PVC cable, Operating voltage: 5 … 60 V, Housing material: Brass with nickel-plating, Degree of protection: IP67.
NBB5-18GM50-E2
Inductive Proximity Sensor, Sensor diameter: M18, Rated operating distance: 5 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 1950 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBN4-12GM50-E0
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 4 mm, Switching function: Normally open (NO), Output type: NPN, Installation: Non-flush, Switching frequency: 0 … 2650 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBN4-12GM50-E0-V1
Sensor diameter: M12, Rated operating distance: 4 mm, Switching function: Normally open (NO), Output type: NPN, Installation: Non-flush, Switching frequency: 0 … 2650 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBN4-12GM50-E2
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 4 mm, Switching function: Normally open (NO), Output type: PNP, Installation: non-flush, Switching frequency: 0 … 2650 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBN4-12GM50-E3
Inductive Proximity Sensor, Rated operating distance: 4 mm, Switching function: Normally closed (NC), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 2650 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBN4-12GM50-E3-V1
Sensor diameter: M12, Rated operating distance: 4 mm, Switching function: Normally closed (NC), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 2650 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
At IndMALL Automation you can easily find the ideal solution for your needs if you’re looking for an Inductive Proximity Switch with specific technical specifications. The Pepperl Fuchs NEN10-12GM50-E2-V1 sensor features a 10mm rated operating distance, PNP output, non-flush installation, and normally open (NO) switching function. This sensor operates with a 3-wire output type, DC output polarity, and an input voltage of 10-30V DC.
Its switching frequency range is 0-600 Hz, making it suitable for various industrial applications. It also has a yellow LED switching state indicator to easily identify its status. The Pepperl Fuchs NEN10-12GM50-E2-V1 sensor has a wide operating temperature range of -25 to 85 °C (-13 to 185 °F) and a sensing face made of PBT.
Its housing material is brass and nickel-plated, providing excellent protection against harsh environments. Connect the sensor, it requires a 4-pin connector plug with an M12 x 1 thread. With all these technical specifications, the Pepperl Fuchs Proximity Sensors is a reliable and durable solution for your proximity switch needs.
You can check the P&F 40mm series with the Connector type.
