Pepperl Fuchs Proximity Sensor NMB3-8GM50-E2-V1
NMB3-8GM50-E2-V1 Technical Specifications:
Looking for a P&F Proximity Sensor NMB3-8GM50-E2-V1 that fits your specific requirements? Your search ends here at IndMALL Automation, where we provide various options such as a 3mm size, PNP output, M12 Connector, and flush type.
| Switching function | Normally Open(NO) | |
| Output type | PNP | |
| Rated operating distance | 3 mm | |
| Installation | flush | |
| Output polarity | DC | |
| Output type | 3-wire | |
| Operating voltage | 10 … 30 V DC | |
| Switching frequency | 0 … 360 Hz | |
| Operation indicator | LED, red | |
| Ambient temperature | -25 … 75 °C (-13 … 167 °F) | |
| Connection type | Connector plug M12 x 1 , 4-pin | |
| Housing material | Stainless steel 1.4305 / AISI 303 | |
| Degree of protection | IP67 | |
Product Documentation: NMB3-8GM50-E2-V1
Related Products: NMB3-8GM50-E2-V1
NCB15-30GM50-Z4-V1
Inductive Proximity Sensor, Sensor diameter: M30, Rated operating distance: 15 mm, Switching function: Normally open (NO), Output type: Two-wire, Output polarity: DC, Installation: flush, Switching frequency: 500 Hz, Type of voltage: DC, Connection type: Connector plug M12 x 1, 4-pin, Operating voltage: 3.5 … 30 V, Housing material: brass, nickel-plated, Degree of protection: IP67.
NCB2-12GM40-Z0
Inductive Proximity Sensor, Rated operating distance: 2 mm, Switching function: Normally open (NO), Output type: Two-wire, Type of voltage: DC, Output polarity: DC, Installation: Flush, Operating voltage: 5 … 60 V, Switching frequency: 0 … 800 Hz, Connection type: Cable PUR 2m, Housing material: Stainless steel 1.4305 / AISI 303, Degree of protection: IP67.
NCB2-12GM40-Z1
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 2 mm, Switching function: Normally closed (NC), Output type: Two-wire, Output polarity: DC, Installation: Flush, Switching frequency: 0 … 800 Hz, Housing material: Stainless steel 1.4305/AISI 303, Sensing face: PBT, Degree of protection: IP67.
NCB2-V3-N0
Namur Inductive Proximity Sensor, Rated operating distance: 2 mm, Switching function: Normally closed (NC), Output type: NAMUR, Installation: Flush, Switching frequency: 0 … 2000 Hz, Output type: 2-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: Nominal voltage of 8.2 V (Ri approx. 1 kΩ), Housing material: PBT, Degree of protection: IP67.
NCB4-12GM35-Z4
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 4 mm, Switching function: Normally open (NO), Output type: 2-wire, Installation: Flush, Switching frequency: 0 … 1000 Hz, Type of voltage: DC, Operating voltage: 3.5 … 30 V, Housing material: Brass with nickel-plated coating, Degree of protection: IP67.
NBB2-8GM40-E2-V3
Inductive Proximity Sensor, Sensor diameter: M8, Rated operating distance: 2 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 6000 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug M8 x 1, 3-pin, Operating voltage: 5 … 30 V, Housing material: Brass, nickel-plated, Degree of protection: IP67.
Product:12 NBB8-18GM50-E2-V1
NBB8-18GM50-E2-V1
Inductive Proximity Sensor, Sensor diameter: M18, Rated operating distance: 8 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 1350 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBN4-12GM50-E2-V1
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 4 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 2650 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBN8-18GM50-E2
Inductive Proximity Sensor, Sensor diameter: M18, Rated operating distance: 8 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 1650 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB15-30GM50-E2-V1
Inductive Proximity Sensor, Sensor diameter: M30, Rated operating distance: 15 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 550 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NCB4-12GM40-Z4-V1
Sensor diameter: M12, Rated operating distance: 4 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 1000 Hz, Output type: 2-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 3.5 … 30 V, Housing material: Brass, nickel-plated, Degree of protection: IP67.
NCB4-12GM50-E2-V1
Sensor diameter: M12, Rated operating distance: 4 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 800 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug M12 x 1, 4-pin, Operating voltage: 10 … 30 V, Housing material: Stainless steel 1.4305 / AISI 303, Degree of protection: IP67.
NCB5-18GM40-Z0-V1
Sensor diameter: M18, Rated operating distance: 5 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 1950 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NCB5-18GM40-Z1
Inductive Proximity Sensor, Sensor diameter: M18, Rated operating distance: 5 mm, Switching function: Normally closed (NC), Output type: Two-wire, Installation: Flush, Switching frequency: 0 … 350 Hz, Type of voltage: DC, Connection type: Cable (PUR, 2m), Operating voltage: 5 … 60 V, Housing material: Stainless steel 1.4305 / AISI 303, Degree of protection: IP67.
NCB50-FP-E2-P1
Inductive Proximity Sensor, Rated operating distance: 50 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 80 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Screw terminals, Operating voltage: 10 … 60 V DC, Housing material: PBT, Degree of protection: IP68.
The Pepperl Fuchs NMB3-8GM50-E2-V1 is a high-performance proximity sensor designed for industrial automation applications. With a normally open (NO) switching function and a PNP output type, this sensor provides reliable and accurate detection of ferrous and non-ferrous targets. It has a rated operating distance of 3 mm and operates on a DC output polarity with a 3-wire output type.
The sensor can be easily installed flush with the surface of the application, making it ideal for use in tight spaces. This Pepperl Fuchs Inductive Sensor operates on an operating voltage of 10 to 30 V DC with a switching frequency of 0 to 360 Hz. An LED red operation indicator provides visual feedback on the switching state of the sensor, allowing for quick and easy diagnosis of issues.
The sensor has a temperature range of -25 to 75 °C (-13 to 167 °F), making it suitable for use in harsh environments. It has sturdy housing made of stainless steel 1.4305 / AISI 303 and is rated IP67, providing protection against dust and water ingress. The NMB3-8GM50-E2 V1 Inductive Proximity Switch uses a connector plug M12 x 1, a 4-pin connection type for easy installation and maintenance.
You can check the P&F 3mm series with the Connector type.
