Home / Products / Photoelectric Sensor / Pepperl Fuchs/ OBG5000-R100-2EP-IO-V31
P&F Retroreflective sensor
OBG5000-R100-2EP-IO-V31
OBG5000-R100-2EP-IO-V31 Technical Specifications:
IndMALL offers the perfect solution for your industrial requirements if you need a sensor with a0 … 3.5 m, Detection range, and a 6m Threshold detection range, LED Light source, modulated visible red Light type, and M8 x 1 connector, 4-pin. Look no further than the P&F Photoelectric Switch OBG5000-R100-2EP-IO-V31 sensor, which is readily available.
| Detection range | 0 … 3.5 m | |
| Threshold detection range | 6m | |
| Reference target | H85-2 reflector | |
| Light source | LED | |
| Operating voltage | 10 … 30 V DC | |
| Light type | modulated visible red light | |
| Switching voltage | max. 30 V DC | |
| Switching type | The switching type of the sensor is adjustable. The default setting is: C/Q – Pin4: NPN normally open / dark-on, PNP normally closed / light-on, IO-Link /Q – Pin2: NPN normally closed / light-on, PNP normally open / dark-on |
|
| Switching frequency | 500 Hz | |
| Response time | 1 ms | |
| Ambient temperature | -20 … 60 °C (-4 … 140 °F) | |
| Degree of protection | IP67 / IP69 / IP69K | |
| Connection | M8 x 1 connector, 4-pin | |
Product Documentation: OBG5000-R100-2EP-IO-V31
Related Products: OBG5000-R100-2EP-IO-V31
OBG5000-R100-2EP-IO-V31
Type:Thru-beam sensor, Detection range: 0 … 3.5 m, Light source: LED, Operating voltage: 10 … 30 V DC, Switching type: Adjustable switching type, Signal output: 2 push-pull (4 in 1) outputs, Switching frequency: 500 Hz, Response time: 1 ms, Housing (WxHxD): 11 mm x 44.5 mm x 21.5 mm, Degree of protection: IP67 / IP69 / IP69K, Connection: M8 x 1 connector, 4-pin, Housing material: PC (Polycarbonate).
OBR15M-R200-2EP-IO-V1
Type:Retroreflective sensor, Detection range: 0 … 15 m, Light source: LED, Operating voltage: 10 … 30 V DC, Switching type: C/Q – Pin4: NPN normally open / dark-on, PNP normally closed / light-on, IO-Link / Q – Pin2: NPN normally closed / light-on, PNP normally open / dark-on, Signal output: 2 push-pull (4 in 1) outputs, short-circuit protected, reverse polarity protected, overvoltage protected, Switching frequency: 1000 Hz, Response time: 0.5 ms, Housing (WxHxD): 15 mm x 50.6 mm x 41.7 mm, Degree of protection: IP67 / IP69 / IP69K, Connection: 4-pin, M12 x 1 connector, 90° rotatable, Housing material: PC (Polycarbonate).
OBT650-R200-2EP-IO-V1
Type:Triangulation sensor, Detection range: 10 … 650 mm, Light source: LED, Operating voltage: 10 … 30 V DC, Switching type: C/Q – Pin4: NPN normally open / light-on, PNP normally closed / dark-on, IO-Link / Q – Pin2: NPN normally closed / dark-on, PNP normally open / light-on, Signal output: 2 push-pull (4 in 1) outputs, short-circuit protected, reverse polarity protected, overvoltage protected, Switching frequency: 500 Hz, Response time: 1 ms, Housing (WxHxD): 15 mm x 50.6 mm x 41.7 mm, Degree of protection: IP67 / IP69 / IP69K, Connection: 4-pin, M12 x 1 connector, 90° rotatable, Housing material: PC (Polycarbonate).
OBT300-R200-2EP-IO-V1
Type:Triangulation sensor, Detection range: 30 … 300 mm, Light source: LED, Operating voltage: 10 … 30 V DC, Switching type: C/Q – Pin4: NPN normally open / light-on, PNP normally closed / dark-on, IO-Link / Q – Pin2: NPN normally closed / dark-on, PNP normally open / light-on, Signal output: 2 push-pull (4 in 1) outputs, short-circuit protected, reverse polarity protected, overvoltage protected, Switching frequency: 500 Hz, Response time: 1 ms, Housing (WxHxD): 15 mm x 50.6 mm x 41.7 mm, Degree of protection: IP67 / IP69 / IP69K, Connection: 4-pin, M12 x 1 connector, 90° rotatable, Housing material: PC (Polycarbonate).
OBS4000-18GM60-E5-V1
Type: Reflective Photo Sensor, Detection range: 0 … 4 m, Light source: LED (modulated visible red light, 660 nm), Operating voltage: 10 … 30 V DC (class 2), Switching type: Light/dark on electrically switchable, Signal output: 1 PNP output, short-circuit protected, reverse polarity protected, open collector, Switching frequency: 500 Hz, Response time: 1 ms, Degree of protection: IP67, Connection: 4-pin, M12 x 1 connector, Housing material: Brass, nickel-plated.
ML100-55/103/115
Type: Reflective Photo Sensor, Detection range: 0 … 5 m, Light source: LED (modulated visible red light), Operating voltage: 10 … 30 V DC, Switching type: Adjustable (default: light-on), Signal output: 1 PNP output, short-circuit protected, reverse polarity protected, open collector, Switching frequency: 1000 Hz, Response time: 0.5 ms, Housing dimensions (WxHxD): 11 mm x 31 mm x 20 mm, Degree of protection: IP67, Connection: 2 m fixed cable, Housing material: PC (Polycarbonate), Cable length: 2 m.
M100/MV100-RT/76a/103/115
Type: Through Beam photoelectric sensor, Detection range: 0 … 10 m (Effective detection range), Light source: LED (modulated visible red light), Operating voltage: 10 … 30 V DC, Switching type: Adjustable (default: light-on), Signal output: 1 PNP output (short-circuit protected, reverse polarity protected, open collector), Switching frequency: 1000 Hz, Response time: 0.5 ms, Housing dimensions: Width 11 mm, Height 31 mm, Depth 20 mm, Degree of protection: IP67, Connection: 2 m fixed cable, Housing material: PC (Polycarbonate), Cable length: 2 m.
GLV18-8-450/115/120
Type: Diffuse photoelectric sensor, Detection range: 50 … 450 mm adjustable, Light source: LED, Operating voltage: 10 … 30 V DC, Switching type: Light/dark-on, Signal output: 2 PNP, complementary, short-circuit protected, open collectors, Switching frequency: 500 Hz, Response time: ≤ 1 ms, Degree of protection: IP67, Connection: 2 m fixed cable, Housing material: PC, Cable Length: 2 m.
ML100-8-1000-RT/103/115
Type: Diffuse photoelectric sensor, Detection range: 0 … 1000 mm, Light source: LED, Operating voltage: 10 … 30 V DC, Switching type: Adjustable (default setting: light-on), Signal output: 1 PNP output, short-circuit protected, reverse polarity protected, open collector Switching frequency: 1000 Hz, Response time: 0.5 ms, Housing: 11 mm x 31 mm x 20 mm, Degree of protection: IP67, Connection: 2 m fixed cable, Housing: PC (Polycarbonate), Cable length: 2 m.
OBE20M-R100-S2EP-IO-V31-L
Type:Thru-beam sensor, Detection range: 0 … 20 m, Light source: Laser diode, Operating voltage: 10 … 30 V DC, Switching type: Adjustable switching type, Signal output: 2 push-pull (4 in 1) outputs, Switching frequency: 1250 Hz, Response time: 0.4 ms, Housing (WxHxD): 11 mm x 44.5 mm x 21.5 mm, Degree of protection: IP67 / IP69 / IP69K, Connection: M8 x 1 connector, 4-pin, Housing material: PC (Polycarbonate).
OBE12M-R100-S2EP-IO-V31
Type:Thru-beam sensor, Detection range: 0 … 12 m, Light source: LED (modulated visible red light), Operating voltage: 10 … 30 V DC, Switching type: Adjustable switching type (default setting: C/Q – Pin4: NPN normally open/dark-on, PNP normally closed/light-on, IO-Link), Signal output: 2 push-pull (4 in 1) outputs, short-circuit protected, reverse polarity protected, overvoltage protected, Switching frequency: 1000 Hz, Response time: 0.5 ms, Housing (WxHxD): 11 mm x 44.5 mm x 21.5 mm, Degree of protection: IP67 / IP69 / IP69K, Connection: M8 x 1 connector, 4-pin, Housing material: PC (Polycarbonate).
OBG5000-R100-2EP-IO
Type:Retroreflective sensor, Detection range: 0 … 3.5 m, Light source: LED (modulated visible red light), Operating voltage: 10 … 30 V DC, Switching type: The switching type of the sensor is adjustable. The default setting is:C/Q – BK: NPN normally open / dark-on, PNP normally closed / light-on, IO-Link, Signal output: 2 push-pull (4 in 1) outputs, short-circuit protected, reverse polarity protected, overvoltage protected, Switching frequency: 500 Hz, Housing (WxHxD): 11 mm x 37.1 mm x 21.5 mm, Degree of protection: IP67 / IP69 / IP69K, Connection: 2 m fixed cable, Housing material: PC (Polycarbonate), Cable Length: 2 m.
OBT50-R2-E2
Type:Triangulation sensor, Detection range: 3 … 50 mm, Light source: LED (modulated visible red light), Operating voltage: 10 … 30 V DC, class 2, Switching type: NO contact / light on, Signal output: 1 PNP output, short-circuit protected, reverse polarity protected, open collector, Switching frequency: Approx. 800 Hz, Response time: 600 µs, ,Housing (WxHxD): 7.5 mm x 24 mm x 11.2 mm ,Degree of protection: IP67 Connection: 2 m fixed cable, Housing material: PC/ABS and TPU, Cable Length: 2 m.
OBT30-R2-E2
Type:Triangulation sensor,Detection range: 1 … 30 mm, Light source: LED (modulated visible red light), Operating voltage: 10 … 30 V DC, Switching type: NO contact / light on, Signal output: 1 PNP output, short-circuit protected, reverse polarity protected, open collector, Switching frequency: Approx. 800 Hz, Response time: 600 µs, Housing (WxHxD): 7.5 mm x 24 mm x 11.2 mm, Degree of protection: IP67, Connection: 2 m fixed cable, Housing material: PC/ABS and TPU, Cable Length: 2 m.
ML17-8-450-115-136
Type:Diffuse mode sensor, Detection range: 10 … 450 mm, Light source: IRED (Infrared Emitting Diode), Operating voltage: 10 … 30 V DC, class 2 , Switching type: Light/dark on, Signal output: 2 push-pull (4 in 1) outputs, short-circuit protected, reverse polarity protected, overvoltage protected, Switching frequency: 500 Hz, Response time: ≤ 1 ms, Housing (WxHxD): 15 mm x 34.5 mm, Degree of protection: IP67, Connection: 10 m fixed cable, Housing material: ABS, Cable Length: 10 m.
ML100-8-H-350-RT/95/103
Type: Background suppression sensor, Detection range: 5 … 350 mm, Light source: LED (modulated visible red light), Operating voltage: 10 … 30 V DC, Switching type: Adjustable (default setting: light-on), Signal output: 1 PNP output, short-circuit protected, reverse polarity protected, open collector, Switching frequency: 500 Hz, Response time: 1 ms, Housing (WxHxD): 11 mm x 31 mm x 20 mm, Degree of protection: IP67, Connection: M8 plug, 4-pin, Housing material: PC (Polycarbonate).
ML100-8-H-350-RT/98/103
Type: Background suppression sensor, Detection range: 5 … 350 mm, Light source: LED (modulated visible red light), Operating voltage: 10 … 30 V DC, Switching type: Adjustable (default setting: light-on), Signal output: 1 PNP output, short-circuit protected, reverse polarity protected, open collector, Switching frequency: 500 Hz, Response time: 1 ms, Housing (WxHxD): 11 mm x 31 mm x 20 mm, Degree of protection: IP67, Connection: M8 plug, 3-pin, Housing material: PC (Polycarbonate).
ML100-8-H-350-RT/103/115b
Type: Background suppression sensor, Detection range: 5 … 350 mm, Light source: LED (modulated visible red light), Operating voltage: 10 … 30 V DC, Switching type: Adjustable (default setting: light-on), Signal output: 1 PNP output, short-circuit protected, reverse polarity protected, open collector, Switching frequency: 500 Hz, Response time: 1 ms, Housing (WxHxD): 11 mm x 31 mm x 20 mm, Degree of protection: IP67, Connection: 300 mm fixed cable with M12 plug, 4-pin, Housing material: PC (Polycarbonate), Cable length: 0.3 m.
ML100-8-H-350-RT/103/115a
Type: Background suppression sensor, Detection range: 5 … 350 mm, Light source: LED (modulated visible red light), Operating voltage: 10 … 30 V DC, Switching type: Adjustable (default setting: light-on), Signal output: 1 PNP output, short-circuit protected, reverse polarity protected, open collector, Switching frequency: 500 Hz, Response time: 1 ms, Housing (WxHxD): 11 mm x 31 mm x 20 mm, Degree of protection: IP67, Connection: 300 mm fixed cable with M8 connector, 4-pin, Housing material: PC (Polycarbonate), Cable length: 0.3 m.
ML100-8-H-350-RT/102/115
Type:Background suppression sensor, Detection range: 5 … 350 mm, Light source: LED (modulated visible red light), Operating voltage: 10 … 30 V DC, Switching type: Adjustable (default setting: light-on), Signal output: 1 NPN output, short-circuit protected, reverse polarity protected, open collector, Switching frequency: 500 Hz, Response time: 1 ms, Housing (WxHxD): 11 mm x 31 mm x 20 mm, Degree of protection: IP67, Connection: 2 m fixed cable, Housing material: PC (Polycarbonate), Cable Length: 2 m.
The P&F Photoelectric Sensor OBG5000-R100-2EP-IO-V31 sensor comes equipped with the following technical specifications: it has a detection range of 0 to 3.5m, a threshold detection range of 6m, and uses an H85-2 reflector as a reference target. The sensor also has an LED light source, operates at a voltage range of 10 to 30 V DC, and uses modulated visible red light as its light type.
The maximum switching voltage for the sensor is 30 V DC and its switching type is adjustable, with the default setting being C/Q – Pin4: NPN normally open / dark-on, PNP normally closed / light-on, IO-Link, and /Q – Pin2: NPN normally closed / light-on, PNP normally open / dark-on. The sensor has a switching frequency of 500 Hz and a response time of 1 ms.
The ambient temperature range for the sensor is -20 to 60 °C (-4 to 140 °F) and it has a degree of protection rating of IP67 / IP69 / IP69K. The sensor uses an M8 x 1 connector with 4 pins for connection.
You can check the P&F Retro Reflective sensor with the connector type.
