Home / Products / Photoelectric Sensor / Pepperl Fuchs/ OBR15M-R200-2EP-IO-V1
Pepperl Fuchs Retroreflective sensor
OBR15M-R200-2EP-IO-V1
OBR15M-R200-2EP-IO-V1 Technical Specifications:
IndMALL is providing a Pepperl Fuchs OBR15M-R200-2EP-IO-V1 Photoelectric Switch with a Retroreflective sensor that has a polarization filter. This switch has a detection range of 0 to 15 meters, with both light and dark modes available, and is fitted with a 4-pin, M12 x 1 connector.
| Effective detection range | 0 … 15 m |
| Reflector distance | 0.02 … 15 m |
| Threshold detection range | 18.5 m |
| Reference target | H85-2 reflector |
| Light type | modulated visible red light |
| Light source | LED |
| Operating voltage | 10 … 30 V DC |
| Signal output | 2 push-pull (4 in 1) outputs, short-circuit protected, reverse polarity protected, overvoltage protected |
| Switching type | The switching type of the sensor is adjustable. The default setting is: C/Q – Pin4: NPN normally open / dark-on, PNP normally closed / light-on, IO-Link /Q – Pin2: NPN normally closed / light-on, PNP normally open / dark-on |
| Response time | 0.5ms |
| Switching voltage | max. 30 V DC |
| Switching frequency | 1000 Hz |
| Ambient temperature | -40 … 60 °C (-40 … 140 °F) |
| Degree of protection | IP67 / IP69 / IP69K |
| Connection | 4-pin, M12 x 1 connector, 90° rotatable |
Product Documentation: OBR15M-R200-2EP-IO-V1
Related Products: OBR15M-R200-2EP-IO-V1
ML100-8-H-350-RT/103/115
Type: Background suppression PhotoSensor, Detection range: 5 … 350 mm, Light source: LED, modulated visible red light, Operating voltage: 10 … 30 V DC, Switching type: Adjustable, default setting: light-on, Signal output: 1 PNP output, short-circuit protected, reverse polarity protected, open collector, Switching frequency: 500 Hz, Response time: 1 ms, Housing (WxHxD): 11 mm x 31 mm x 20 mm, Degree of protection: IP67, Connection: 2 m fixed cable, Housing material: PC (Polycarbonate), Cable Length: 2 m
OBP120-R100-2EP-IO-V31-L
Type: Trigger Marks Sensor PhotoSensor, Detection range: 25 … 120 mm, Light source: Laser diode, modulated visible red light, Operating voltage: 10 … 30 V DC, Switching type: Adjustable switching type, default setting: light-on, Signal output: 2 push-pull (4 in 1) outputs, short-circuit protected, reverse polarity protected, overvoltage protected, Switching frequency: 3300 Hz, Response time: 125 µs, Housing (WxHxD): 11 mm x 44.5 mm x 21.5 mm, Degree of protection: IP67 / IP69 / IP69K, Connection: M8 x 1 connector, 4-pin, Housing material: PC (Polycarbonate).
OBT350-R100-2EP-IO-V31
Type: Triangulation sensor, Detection range: 5 … 350 mm, Light source: LED, modulated visible red light, Operating voltage: 10 … 30 V DC, Switching type: Adjustable switching type, default setting: light-on, Signal output: 2 push-pull (4 in 1) outputs, short-circuit protected, reverse polarity protected, overvoltage protected, Switching frequency: 500 Hz, Response time: 1 ms, Housing (WxHxD): 11 mm x 44.5 mm x 21.5 mm, Degree of protection: IP67 / IP69 / IP69K, Connection: M8 x 1 connector, 4-pin, Housing material: PC (Polycarbonate).
OBT500-18GM60-E5-V1
Type: Diffuse mode Photosensor, Detection range: 0 … 500 mm, Light source: IRED (Infrared Emitting Diode), 880 nm, Operating voltage: 10 … 30 V DC, class 2, Switching type: Light/dark-on, electrically switchable, Signal output: 1 PNP output, short-circuit protected, reverse polarity protected, open collector, Switching voltage: Max. 30 V DC, Switching current: Max. 100 mA, Voltage drop: ≤ 2.5 V, Switching frequency: 500 Hz, Response time: 1 ms, Degree of protection: IP67, Connection: 4-pin, M12 x 1 connector, Housing material: Brass, nickel-plated.
OBT200-18GM60-E5-V1
Type: Diffuse mode Photosensor, Detection range: 0 … 200 mm, Light source: IRED (Infrared Emitting Diode), 880 nm, Operating voltage: 10 … 30 V DC, class 2, Switching type: Light/dark-on, electrically switchable, Signal output: 1 PNP output, short-circuit protected, reverse polarity protected, open collector, Switching voltage: Max. 30 V DC, Switching frequency: 500 Hz, Response time: 1 ms, Housing (WxHxD): Not specified, Degree of protection: IP67, Connection: 4-pin, M12 x 1 connector, Housing material: Brass, nickel-plated.
RLK28-8-H-2000-IR-Z/31/116
Type: Background suppression sensor, Detection range: 20 … 2000 mm, Light source: IRED (Infrared), Operating voltage: 12 … 240 V AC/DC, Switching type: Light/dark-on, switchable, Signal output: Relay, 1 alternator, Switching frequency: 25 Hz, Response time: 20 ms, Housing (WxHxD): 25.8 mm x 88 mm x 65.5 mm, Degree of protection: IP67, Connection: Terminal compartment with 8 spring-loaded terminals, Housing material: Plastic ABS.
RL28-8-H-2000-IR/47/105
Type: Background suppression sensor, Detection range: 20 … 2000 mm, Light source: IRED (Infrared), Operating voltage: 10 … 30 V DC, Switching type: Light/dark on switchable, Signal output: 2 PNP, complementary, short-circuit protected, reverse polarity protected, open collectors, Switching frequency: 250 Hz, Response time: 2 ms, Housing (WxHxD): 25.8 mm x 88 mm x 54.3 mm, Degree of protection: IP67, Connection: 5-pin, M12 x 1 connector, Housing material: Plastic ABS.
RL28-8-H-2000-IR/105/110
Type: Background suppression sensor, Detection range: 20 … 2000 mm, Light source: IRED (Infrared), Operating voltage: 10 … 30 V DC, Switching type: Light/dark on switchable, Signal output: 1 push-pull (4 in 1) output, short-circuit protected, reverse polarity protected, Switching frequency: 250 Hz, Response time: 2 ms, Housing (WxHxD): 25.8 mm x 88 mm x 54.3 mm, Degree of protection: IP67, Connection: 5-pin, M12 x 1 connector, Housing material: Plastic ABS.
M100-MV100-RT-76b-102-115
Type: Thru-beam sensor, Detection range: 0 … 10 m, Light source: LED (modulated visible red light), Operating voltage: 10 … 30 V DC, Switching type: Light/dark on (adjustable), Signal output: 1 NPN output, short-circuit protected, reverse polarity protected, open collector, Switching frequency: 1000 Hz, Response time: 0.5 ms, Housing (WxHxD): 11 mm x 31 mm x 20 mm, Degree of protection: IP67, Connection: 2 m fixed cable, Housing material: PC (Polycarbonate), Cable Length: 2 m.
ML100-55-G/102/115
Type: Retroreflective sensor, Detection range: 0 … 2.5 m, Light source: LED (modulated visible red light), Operating voltage: 10 … 30 V DC, Switching type: Adjustable (default setting: light-on), Signal output: 1 NPN output, short-circuit protected, reverse polarity protected, open collector, Switching frequency: 1000 Hz, Response time: 0.5 ms, Housing (WxHxD): 11 mm x 31 mm x 20 mm, Degree of protection: IP67, Connection: 2 m fixed cable, Housing material: PC (Polycarbonate), Cable Length: 2 m.
ML100-55-G/95/103
Type: Retroreflective sensor, Detection range: 0 … 2.5 m, Light source: LED (modulated visible red light), Operating voltage: 10 … 30 V DC, Switching type: Adjustable (default setting: light-on), Signal output: 1 PNP output, short-circuit protected, reverse polarity protected, open collector, Switching frequency: 1000 Hz, Response time: 0.5 ms, Housing (WxHxD): 11 mm x 31 mm x 20 mm, Degree of protection: IP67, Connection: Connector M8 x 1, 4-pin, Housing material: PC (Polycarbonate).
ML100-55-G-103-115
Type: Retroreflective sensor, Detection range: 0 … 5 m, Light source: LED (modulated visible red light), Operating voltage: 10 … 30 V DC, Switching type: Adjustable (default setting: light-on), Signal output: 1 PNP output, short-circuit protected, reverse polarity protected, open collector, Switching frequency: 1000 Hz, Response time: 0.5 ms, Housing (WxHxD): 11 mm x 31 mm x 20 mm, Degree of protection: IP67, Connection: 2 m fixed cable, Housing material: PC (Polycarbonate), Cable length: 2 m.
ML100-55/95/102
Type: Retroreflective sensor, Detection range: 0 … 5 m, Light source: LED (modulated visible red light), Operating voltage: 10 … 30 V DC, Switching type: Adjustable (default setting: light-on), Signal output: 1 NPN output, short-circuit protected, reverse polarity protected, open collector, Switching frequency: 1000 Hz, Response time: 0.5 ms, Housing (WxHxD): 11 mm x 31 mm x 20 mm, Degree of protection: IP67, Connection: M8 plug, 4-pin, Housing material: PC (Polycarbonate).
ML100-55/98/103
Type: Retroreflective sensor, Detection range: 0 … 5 m, Light source: LED (modulated visible red light), Operating voltage: 10 … 30 V DC, Switching type: Adjustable (default setting: light-on), Signal output: 1 PNP output, short-circuit protected, reverse polarity protected, open collector, Switching frequency: 1000 Hz, Response time: 0.5 ms, Housing (WxHxD): 11 mm x 31 mm x 20 mm, Degree of protection: IP67, Connection: M8 plug, 3-pin, Housing material: PC (Polycarbonate).
ML100-55/102/115
Type: Retroreflective sensor, Detection range: 0 … 5 m, Light source: LED (modulated visible red light), Operating voltage: 10 … 30 V DC, Switching type: Adjustable (default setting: light-on), Signal output: 1 NPN output, short-circuit protected, reverse polarity protected, open collector, Switching frequency: 1000 Hz, Response time: 0.5 ms, Housing (WxHxD): 11 mm x 31 mm x 20 mm, Degree of protection: IP67, Connection: 2 m fixed cable, Housing material: PC (Polycarbonate), Cable Length: 2 m.
ML100-55-103-115a
Type: Retroreflective sensor, Detection range: 0 … 5 m, Light source: LED (modulated visible red light), Operating voltage: 10 … 30 V DC, Switching type: Adjustable (default setting: light-on), Signal output: 1 PNP output, short-circuit protected, reverse polarity protected, open collector, Switching frequency: 1000 Hz, Response time: 0.5 ms, Housing (WxHxD): 11 mm x 31 mm x 20 mm, Degree of protection: IP67, Connection: 300 mm fixed cable with M8 connector, 4-pin, Housing material: PC (Polycarbonate), Cable Length: 0.3 m.
ML100-8-H-100-RT/103/115
Type: Background suppression sensor, Detection range: 5 … 100 mm, Light source: LED (modulated visible red light), Operating voltage: 10 … 30 V DC, Switching type: Adjustable (default setting: light-on), Signal output: 1 PNP output, short-circuit protected, reverse polarity protected, open collector, Switching frequency: 1000 Hz, Response time: 0.5 ms, Housing (WxHxD): 11 mm x 31 mm x 20 mm, Degree of protection: IP67, Connection: 2 m fixed cable, Housing material: PC (Polycarbonate), Cable Length: 2 m.
ML100-8-H-350-RT/102/115
Type: Background suppression sensor, Detection range: 5 … 350 mm, Light source: LED (modulated visible red light), Operating voltage: 10 … 30 V DC, Switching type: Adjustable (default setting: light-on), Signal output: 1 NPN output, short-circuit protected, reverse polarity protected, open collector, Switching frequency: 500 Hz, Response time: 1 ms, Housing (WxHxD): 11 mm x 31 mm x 20 mm, Degree of protection: IP67, Connection: 2 m fixed cable, Housing material: PC (Polycarbonate), Cable Length: 2 m.
ML100-8-H-350-RT/103/115a
Type: Background suppression sensor, Detection range: 5 … 350 mm, Light source: LED (modulated visible red light), Operating voltage: 10 … 30 V DC, Switching type: Adjustable (default setting: light-on), Signal output: 1 PNP output, short-circuit protected, reverse polarity protected, open collector, Switching frequency: 500 Hz, Response time: 1 ms, Housing (WxHxD): 11 mm x 31 mm x 20 mm, Degree of protection: IP67, Connection: 300 mm fixed cable with M8 connector, 4-pin, Housing material: PC (Polycarbonate), Cable length: 0.3 m.
ML100-8-H-350-RT/103/115b
Type: Background suppression sensor, Detection range: 5 … 350 mm, Light source: LED (modulated visible red light), Operating voltage: 10 … 30 V DC, Switching type: Adjustable (default setting: light-on), Signal output: 1 PNP output, short-circuit protected, reverse polarity protected, open collector, Switching frequency: 500 Hz, Response time: 1 ms, Housing (WxHxD): 11 mm x 31 mm x 20 mm, Degree of protection: IP67, Connection: 300 mm fixed cable with M12 plug, 4-pin, Housing material: PC (Polycarbonate), Cable length: 0.3 m.
IndMALL Automation is providing a Pepperl Fuchs OBR15M-R200-2EP-IO-V1 Photoelectric Switch that comes with a retroreflective sensor featuring a polarization filter. The switch has an effective detection range of 0 to 15 meters and can operate in both light and dark modes. It is equipped with a 4-pin, M12 x 1 connector, and its light source is a modulated visible red LED.
The p&f photoelectric sensor switching type is adjustable, and it comes with a default setting of C/Q – Pin4: NPN normally open/dark-on, PNP normally closed/light-on, IO-Link/Q – Pin2: NPN normally closed/light-on, PNP normally open/dark-on. The signal output of the switch consists of 2 push-pull (4 in 1) outputs that are short-circuit, reverse polarity, and overvoltage protected. The switch has a response time of 0.5ms, and its maximum switching voltage is 30 V DC.
Furthermore, the Pepperl Fuchs OBR15M-R200-2EP-IO-V1 Photoelectric Switch has a switching frequency of 1000 Hz and can operate in a wide range of ambient temperatures, from -40 to 60°C (-40 to 140°F). It also has a degree of protection of IP67/IP69/IP69K, making it suitable for use in harsh environments. Finally, the switch’s threshold detection range is 18.5 meters, and it comes with an H85-2 reflector as a reference target.
You can check the P&F Retroreflective sensor with connector type.
