P&F Retroreflective Sensor
RL31-54/73c/136
If you need a sensor with Retroreflective sensor with polarization filter, plastic housing, 9 m detection range, red light, dark on, DC version, 2 push-pull outputs, no control elements, and M12 plug? Challaturu offers the perfect solution for the P&F Photoelectric Switch RL31-54/73c/136 sensor, which is readily available.
RL31-54/73c/136 Technical Specifications:
| Detection range | 0 … 9000 mm | |
| Threshold detection range | 12 m | |
| Reflector distance | 20 … 9000 mm | |
| Reference target | reflector C110-2 | |
| Light source | LED | |
| Light type | modulated visible red light, 630 nm | |
| Operation indicator | LED green: power on | |
| Operating voltage | 10 … 30 V DC | |
| Switching voltage | max. 240 V AC | |
| Signal output | 2 push-pull (4 in 1) outputs, short-circuit protected, reverse polarity protected | |
| Switching type | dark-on | |
| Switching frequency | ≤ 500 Hz | |
| Response time | ≤ 1 ms | |
| Ambient temperature | -30 … 55 °C (-22 … 131 °F) | |
| Degree of protection | IP67 | |
| Connection | 4-pin, M12 x 1 connector | |
Product Documentation: RL31-54/73c/136
Related Products: RL31-54/73c/136
OBT200-18GM60-E5
Type: Diffuse-type Sensor, Detection range: 0 … 200 mm, Light source: IRED (Infrared), 880 nm, Operating voltage: 10 … 30 V DC, Switching type: Light/dark-on, electrically switchable, Signal output: 1 PNP output, short-circuit protected, reverse polarity protected, open collector, Switching frequency: 500 Hz, Response time: 1 ms, Housing dimensions (WxHxD): Not specified, Degree of protection: IP67, Connection: 2 m fixed cable, Housing material: Brass, nickel-plated, Cable length: 2 m.
OBT350-R100-2EP-IO-V31
Type: Triangulation sensor, Detection range: 5 … 350 mm, Light source: LED, modulated visible red light, Operating voltage: 10 … 30 V DC, Switching type: Adjustable switching type, default setting: light-on, Signal output: 2 push-pull (4 in 1) outputs, short-circuit protected, reverse polarity protected, overvoltage protected, Switching frequency: 500 Hz, Response time: 1 ms, Housing (WxHxD): 11 mm x 44.5 mm x 21.5 mm, Degree of protection: IP67 / IP69 / IP69K, Connection: M8 x 1 connector, 4-pin, Housing material: PC (Polycarbonate).
ML100-8-H-350-RT/103/115
Type: Background suppression PhotoSensor, Detection range: 5 … 350 mm, Light source: LED, modulated visible red light, Operating voltage: 10 … 30 V DC, Switching type: Adjustable, default setting: light-on, Signal output: 1 PNP output, short-circuit protected, reverse polarity protected, open collector, Switching frequency: 500 Hz, Response time: 1 ms, Housing (WxHxD): 11 mm x 31 mm x 20 mm, Degree of protection: IP67, Connection: 2 m fixed cable, Housing material: PC (Polycarbonate), Cable Length: 2 m.
OBT500-18GM60-E5
Type: Diffuse Type PhotoSensor, Detection range: 0 … 500 mm, Light source: IRED (Infrared), 880 nm, Operating voltage: 10 … 30 V DC, Switching type: Light/dark-on, electrically switchable, Signal output: 1 PNP output, short-circuit protected, reverse polarity protected, open collector, Switching frequency: 500 Hz, Response time: 1 ms, Degree of protection: IP67, Connection: 2 m fixed cable, Housing material: Brass, nickel-plated, Cable length: 2 m.
OBT30-R2F-E2
Type: Triangulation Sensor, Detection range: 1 … 30 mm, Light source: LED (modulated visible red light, 630 nm), Operating voltage: 10 … 30 V DC, Switching type: NO contact / light-on, Signal output: 1 PNP output, short-circuit protected, reverse polarity protected, open collector, Switching frequency: Approx. 1 kHz, Response time: 500 µs, Housing (WxHxD): 12 mm x 25.5 mm x 4.1 mm, Degree of protection: IP67, Connection: 2 m fixed cable, Housing material: PC (Polycarbonate) and Stainless steel, Cable Length: 2 m.
M100-MV100-RT-76b-102-115
Type:Thru-beam sensor, Detection range: 0 … 10 m, Light source: LED (modulated visible red light), Operating voltage: 10 … 30 V DC, Switching type: Light/dark on (adjustable), Signal output: 1 NPN output, short-circuit protected, reverse polarity protected, open collector, Switching frequency: 1000 Hz, Response time: 0.5 ms, Housing (WxHxD): 11 mm x 31 mm x 20 mm, Degree of protection: IP67, Connection: 2 m fixed cable, Housing material: PC (Polycarbonate), Cable Length: 2 m.
ML100-8-H-100-RT/103/115
Type:Background suppression sensor, Detection range: 5 … 100 mm, Light source: LED (modulated visible red light), Operating voltage: 10 … 30 V DC, Switching type: Adjustable (default setting: light-on), Signal output: 1 PNP output, short-circuit protected, reverse polarity protected, open collector, Switching frequency: 1000 Hz, Response time: 0.5 ms, Housing (WxHxD): 11 mm x 31 mm x 20 mm, Degree of protection: IP67, Connection: 2 m fixed cable, Housing material: PC (Polycarbonate), Cable Length: 2 m.
ML100-8-H-350-RT/103/115a
Type: Background suppression sensor, Detection range: 5 … 350 mm, Light source: LED (modulated visible red light), Operating voltage: 10 … 30 V DC, Switching type: Adjustable (default setting: light-on), Signal output: 1 PNP output, short-circuit protected, reverse polarity protected, open collector, Switching frequency: 500 Hz, Response time: 1 ms, Housing (WxHxD): 11 mm x 31 mm x 20 mm, Degree of protection: IP67, Connection: 300 mm fixed cable with M8 connector, 4-pin, Housing material: PC (Polycarbonate), Cable length: 0.3 m.
GD18/GV18/73/120
Type:Thru-beam sensor, Detection range: 0 … 20 m, Light source: LED (modulated visible red light, 640 nm), Operating voltage: 10 … 30 V DC, Switching type: Light/dark on, Signal output: 2 PNP, complementary, short-circuit protected, open collectors, Switching frequency: 500 Hz, Response time: ≤ 1 ms, Housing (WxHxD): N/A (not provided in the information), Degree of protection: IP67, Connection: 4-pin, M12 x 1 connector, Housing material: PC (Polycarbonate).
M100/MV100-RT/76a/95/103
Type:Thru-beam sensor, Detection range: 0 … 10 m, Light source: LED (modulated visible red light), Operating voltage: 10 … 30 V DC, Switching type: Light/dark on (adjustable), Signal output: 1 PNP output, short-circuit protected, reverse polarity protected, open collector, Switching frequency: 1000 Hz, Response time: 0.5 ms, Housing (WxHxD): 11 mm x 31 mm x 20 mm, Degree of protection: IP67, Connection: M8 plug, 4-pin, Housing material: PC (Polycarbonate).
OBE12M-R100-S2EP-IO-V31
Type:Thru-beam sensor, Detection range: 0 … 12 m, Light source: LED (modulated visible red light), Operating voltage: 10 … 30 V DC, Switching type: Adjustable switching type (default setting: C/Q – Pin4: NPN normally open/dark-on, PNP normally closed/light-on, IO-Link), Signal output: 2 push-pull (4 in 1) outputs, short-circuit protected, reverse polarity protected, overvoltage protected, Switching frequency: 1000 Hz, Response time: 0.5 ms, Housing (WxHxD): 11 mm x 44.5 mm x 21.5 mm, Degree of protection: IP67 / IP69 / IP69K, Connection: M8 x 1 connector, 4-pin, Housing material: PC (Polycarbonate).
OBG5000-R100-2EP-IO-V31
Type:Thru-beam sensor, Detection range: 0 … 3.5 m, Light source: LED, Operating voltage: 10 … 30 V DC, Switching type: Adjustable switching type, Signal output: 2 push-pull (4 in 1) outputs, Switching frequency: 500 Hz, Response time: 1 ms, Housing (WxHxD): 11 mm x 44.5 mm x 21.5 mm, Degree of protection: IP67 / IP69 / IP69K, Connection: M8 x 1 connector, 4-pin, Housing material: PC (Polycarbonate).
OBT40-R102-2P1-IO-V31
Type:Triangulation sensor, Detection range: 10 … 40 mm, Light source: LED, Operating voltage: 10 … 30 V DC, Switching type: C/Q – Pin4: NPN normally closed / dark-on, PNP normally open / light-on, IO-Link / Q – Pin2: NPN normally open / light-on, PNP normally closed / dark-on, Signal output: 2 push-pull (4 in 1) outputs, short-circuit protected, reverse polarity protected, overvoltage protected, Switching frequency: 500 Hz, Response time: 1 ms, Housing (WxHxD): 13.9 mm x 31.9 mm x 18.3 mm, Degree of protection: IP67 / IP69 / IP69K, Connection: M8 x 1 connector, 4-pin, Housing material: PC (Polycarbonate).
OBR15M-R200-2EP-IO-V1
Type:Retroreflective sensor, Detection range: 0 … 15 m, Light source: LED, Operating voltage: 10 … 30 V DC, Switching type: C/Q – Pin4: NPN normally open / dark-on, PNP normally closed / light-on, IO-Link / Q – Pin2: NPN normally closed / light-on, PNP normally open / dark-on, Signal output: 2 push-pull (4 in 1) outputs, short-circuit protected, reverse polarity protected, overvoltage protected, Switching frequency: 1000 Hz, Response time: 0.5 ms, Housing (WxHxD): 15 mm x 50.6 mm x 41.7 mm, Degree of protection: IP67 / IP69 / IP69K, Connection: 4-pin, M12 x 1 connector, 90° rotatable, Housing material: PC (Polycarbonate).
RLK31-8-1200-RT/31/115
Type:Diffuse mode Photosensor, Detection range: 0 … 1200 mm adjustable, Light source: LED, modulated visible red light, 630 nm, Operating voltage: 24 … 240 V AC, 12 … 240 V DC, Switching type: Light-on, Signal output: Relay, 1 alternator, Switching frequency: 20 Hz, Response time: ≤ 25 ms, Housing (WxHxD): 18 mm x 62 mm x 35 mm, Degree of protection: IP67, Connection: 2 m fixed cable, 5-wire, Housing material: Polycarbonate, Cable Length: 2 m.
RL31-8-H-800-RT-IO/59/73c/136
Type:Diffuse mode sensor , Detection range: 50 … 800 mm, Light source: LED, Operating voltage: 10 … 30 V DC, Switching type: Dark-on, Signal output: 2 push-pull (4 in 1) outputs, short-circuit protected, reverse polarity protected, Switching frequency: 200 Hz, Response time: 2.5 ms, Housing (WxHxD): 18 mm x 62 mm x 35 mm, Degree of protection: IP67, Connection: 4-pin, M12 x 1 connector, Housing material: Polycarbonate.
RL28-8-H-2000-IR/47/105
Type:Background suppression sensor, Detection range: 20 … 2000 mm, Light source: IRED (Infrared), Operating voltage: 10 … 30 V DC, Switching type: Light/dark on switchable, Signal output: 2 PNP, complementary, short-circuit protected, reverse polarity protected, open collectors, Switching frequency: 250 Hz, Response time: 2 ms, Housing (WxHxD): 25.8 mm x 88 mm x 54.3 mm, Degree of protection: IP67, Connection: 5-pin, M12 x 1 connector, Housing material: Plastic ABS.
RL28-8-H-2000-IR/105/110
Type:Background suppression sensor, Detection range: 20 … 2000 mm, Light source: IRED (Infrared), Operating voltage: 10 … 30 V DC, Switching type: Light/dark on switchable, Signal output: 1 push-pull (4 in 1) output, short-circuit protected, reverse polarity protected, Switching frequency: 250 Hz, Response time: 2 ms, Housing (WxHxD): 25.8 mm x 88 mm x 54.3 mm, Degree of protection: IP67, Connection: 5-pin, M12 x 1 connector, Housing material: Plastic ABS.
RL29-8-2000/59/73c/136
Type:Diffuse mode sensor, Detection range: 0 … 2000 mm, Light source: LED (640 nm), Operating voltage: 10 … 30 V DC, class 2, Switching type: Dark-on, Signal output: 2 push-pull (4 in 1) outputs, short-circuit protected, reverse polarity protected, Switching frequency: 125 Hz, Response time: 4 ms, Housing (WxHxD): 25.8 mm x 88 mm x 54.3 mm, Degree of protection: IP65, Connection: Plastic connector M12 x 1, 4-pin, Housing material: Plastic ABS.
RLK28-8-H-2000-IR-Z/31/116
Type:Background suppression sensor, Detection range: 20 … 2000 mm, Light source: IRED (Infrared), Operating voltage: 12 … 240 V AC/DC, Switching type: Light/dark on, switchable, Signal output: Relay, 1 alternator, Switching frequency: 25 Hz, Response time: 20 ms, Housing (WxHxD): 25.8 mm x 88 mm x 65.5 mm, Degree of protection: IP67, Connection: Terminal compartment with 8 spring-loaded terminals, Housing material: Plastic ABS.
The P&F Photoelectric Sensor RL31-54/73c/136 is a sensor that has a detection range of 0 to 9000 mm, with a threshold detection range of 12 m and a reflector distance of 20 to 9000 mm. Its reference target is a reflector C110-2 and uses a modulated visible red light with a wavelength of 630 nm as its light source. An LED green indicator is present to show its power status.
This sensor operates at an operating voltage of 10 to 30 V DC and has a maximum switching voltage of 240 V AC. Its signal output consists of 2 push-pull (4 in 1) outputs, which are short-circuit protected and reverse polarity protected. The switching type of this sensor is dark-on, and its switching frequency is up to 500 Hz.
The response time of this sensor is less than or equal to 1 ms, and it can operate in ambient temperatures ranging from -30 to 55 °C (-22 to 131 °F). Its degree of protection is IP67, and it uses a 4-pin, M12 x 1 connector for connection.
