Pepperl Fuchs Ultrasonic Sensors
Pepperl+Fuchs is known for high-quality ultrasonic sensors. These sensors use sound waves to measure distance and detect objects. They work well in various conditions, even with dust and dirt around. Different series like UC2000, UB800, and UBE1000 offer a range of sizes and features.
For instance, some have short designs, while others have longer sensing ranges. Pepperl+Fuchs Ultrasonic Sensors also offer different outputs like analog or switch outputs. Key features include temperature compensation, synchronization options, and programmability.
These Ultrasonic sensors are built tough with IP67 or IP65 protection, ensuring they last long even in tough environments. IndMALL provides these reliable sensors, ideal for many industrial applications.
UC2000-30GM-2EP-IO-V15
- Series: UC2000
- Design: Single-head system, Cylindrical
- Sensing Range: 90 … 2000 mm
- Operating Principle: Ultrasonic
- Switching Principle: 2 push-pull (4 in 1) outputs, programmable
- Operating Voltage: 10 … 30 V DC
- Frequency: Approx. 200 kHz
- Protection: IP67, Stainless Steel Housing
UB800-18GM40-U-V1
- Series: UB800
- Design: Single Head System, Short (40 mm)
- Sensing Range: 50 … 800 mm
- Output Type: 1 Analog Output 0 … 10 V
- Operating Voltage: 15 … 30 V DC
- Frequency: Approx. 255 kHz
- Response Delay: Approx. 100 ms
- Protection: IP67
UC2000-L2-E5-V15
- Series: UC2000
- Design: Single Head System, Bidirectional and Rotatable Sensor Head
- Sensing Range: 60 … 2000 mm
- Operating Principle: Ultrasonic
- Switching Principle: PNP NO/NC, Programmable
- Operating Voltage: 10 … 30 V DC
- Frequency: Approx. 175 kHz
- Protection: IP67
UBE1000-18GM40-SE2-V1
- Series: UBE1000
- Design: Single Head System, Short (40 mm)
- Sensing Range: 15 … 1000 mm
- Operating Principle: Ultrasonic
- Switching Principle: PNP, NO (Normally Open)
- Operating Voltage: 10 … 30 V DC
- Frequency: Approx. 255 kHz
- Protection: IP67
UBE1000-18GM40A-SE2-V1-Y205349
- Series: UBE1000
- Design: Single Head System, Short (40 mm), Cylindrical
- Sensing Range: 15 … 1000 mm
- Operating Principle: Ultrasonic
- Switching Principle: PNP, NO (Normally Open)
- Operating Voltage: 10 … 30 V DC
- Frequency: Approx. 255 kHz
- Protection: IP67
UBE4000-30GM-SA2-V15
- Series: UBE4000
- Design: Through-beam Ultrasonic Barrier
- Sensing Range: 500 … 4000 mm
- Operating Principle: Ultrasonic
- Switching Principle: 2 Switch Outputs PNP, NO/NC (Normally Open/Closed, Complementary)
- Operating Voltage: 18 … 30 V DC
- Frequency: 85 kHz
UB2000-30GM-E5-V15
- Series: UB2000
- Design: Single Head System
- Sensing Range: 80 … 2000 mm
- Operating Principle: Ultrasonic
- Switching Principle: 1 Switch Output PNP, NO/NC (Normally Open/Closed), Programmable
- Operating Voltage: 10 … 30 V DC
- Frequency: Approx. 180 kHz
UB250-F77-E2-V31
- Series: UB250
- Design: Ultrasonic Direct Detection, Miniature
- Sensing Range: 20 … 250 mm
- Switching Principle: 1 Switch Output PNP, NO (Normally Open)
- Operating Voltage: 20 … 30 V DC
- Frequency: Approx. 400 kHz
- Response Delay: ≤ 50 ms
- Protection: IP67
UGB-18GM50-255-2E1
- Series: UGB
- Design: Ultrasonic System for Splice Detection, Short Version
- Sensing Range: 20 … 60 mm, Optimal Distance: 45 mm
- Switching Principle: 2 Switch Outputs NPN, NC (Normally Closed)
- Operating Voltage: 18 … 30 V DC
- Frequency: 255 kHz
- Response Delay: < 500 ms
- Protection: IP67
UC2000-30GM70-2E2R2-V15
- Series: UC2000
- Design: Cylindrical, Ultrasonic Direct Detection
- Sensing Range: 100 … 2000 mm
- Operating Principle: Ultrasonic
- Switching Principle: 2 Switch Outputs PNP, NO
- Operating Voltage: 12 … 30 V DC
- Frequency: Approx. 200 kHz
- Protection: IP65
UC4000-30GM-IUR2-V15
- Series: UC4000
- Design: Single Head System, Cylindrical
- Sensing Range: 200 … 4000 mm
- Operating Principle: Ultrasonic
- Output Type: 1 Current Output 4 … 20 mA, 1 Voltage Output 0 … 10 V
- Operating Voltage: 10 … 30 V DC
- Frequency: Approx. 85 kHz
- Protection: IP65
UB1000-18GM75-E5-V15
- Series: UB1000
- Design: Single Head System, Cylindrical
- Sensing Range: 70 … 1000 mm
- Operating Principle: Ultrasonic
- Switching Principle: 1 Switch Output PNP, NO/NC
- Operating Voltage: 10 … 30 V DC
- Frequency: Approx. 255 kHz
- Protection: IP67
UC6000-30GM-IUR2-V15
- Series: UC6000
- Design: Single Head System, Cylindrical
- Sensing Range: 350 … 6000 mm
- Operating Principle: Ultrasonic
- Output Type: 1 Current Output 4 … 20 mA, 1 Voltage Output 0 … 10 V
- Operating Voltage: 10 … 30 V DC
- Frequency: Approx. 65 kHz
- Protection: IP65
UB800-18GM40-I-V1
- Series: UB800
- Design: Single Head System, Short (40 mm), Cylindrical
- Sensing Range: 50 … 800 mm
- Operating Principle: Ultrasonic
- Output Type: 1 Analog Output 4 mA … 20 mA
- Operating Voltage: 10 … 30 V DC
- Frequency: Approx. 255 kHz
- Protection: IP67
UB120-12GM-E5-V1
- Series: UB120
- Design: Single Head System, Cylindrical
- Sensing Range: 15 … 120 mm
- Operating Principle: Ultrasonic
- Switching Principle: 1 Switch Output PNP, NO/NC
- Operating Voltage: 10 … 30 V DC
- Frequency: Approx. 850 kHz
- Protection: IP67
UB500-F42S-U-V15
- Series: UB500
- Design: Single Head System, Cylindrical
- Sensing Range: 30 … 500 mm
- Operating Principle: Ultrasonic
- Output Type: 1 Analog Output 0 … 10 V
- Operating Voltage: 17 … 30 V DC
- Frequency: Approx. 390 kHz
- Protection: IP54
UB300-18GM40-E5-V1
- Series: UB300
- Design: Single Head System, Short (40 mm), Cylindrical
- Sensing Range: 35 … 300 mm
- Operating Principle: Ultrasonic
- Switching Principle: 1 Switching Output E5, PNP NO/NC
- Operating Voltage: 10 … 30 V DC
- Frequency: Approx. 390 kHz
- Protection: IP67
UB800-18GM40A-U-V1
- Series: UB800
- Design: Single Head System, Short (40 mm), Cylindrical
- Sensing Range: 50 … 800 mm
- Operating Principle: Ultrasonic
- Output Type: 1 Analog Output 0 … 10 V
- Operating Voltage: 15 … 30 V DC
- Frequency: Approx. 255 kHz
- Protection: IP67
UC6000-30GM70-IE2R2-V15
- Series: UC6000
- Design: Cylindrical, Ultrasonic Direct Detection
- Sensing Range: 350 … 6000 mm
- Operating Principle: Ultrasonic
- Output Type: 1 Analog Output 4 … 20 mA, 1 Switch Output PNP NO
- Operating Voltage: 20 … 30 V DC
- Frequency: Approx. 80 kHz
- Protection: IP65
Frequently Asked Questions
What is the working principle of ultrasonic sensor?
Ultrasonic sensors work by sending out sound waves. These waves are too high-pitched for humans to hear. The sensor sends out these waves and waits for them to bounce back, like an echo.
When these waves hit an object, they bounce back to the sensor. By measuring the time it takes for the waves to return, the sensor can tell how far away the object is.
What is the range of ultrasonic sensor?
The range of an ultrasonic sensor is how far it can detect objects. Different sensors have different ranges. Some can detect things that are very close, within a few centimeters. Others can detect objects several meters away. The specific range depends on the sensor’s design and how it’s used.
How do you test an ultrasonic sensor?
To test an ultrasonic sensor, you need a target to detect. You can use any object like a wall or a hand. Place the object at different distances from the sensor. The sensor should detect the object and give a reading of the distance. If the readings are accurate for different distances, the sensor is working well. This is a simple way to make sure your sensor is doing its job.
