ETD-SL-2T-I: 2866174 - Phoenix 8mm Stripping Length Timer Relay
Technical Specifications of Phoenix 8mm Stripping Length Timer Relay ETD-SL-2T-I 2866174:
| Spec | Value |
|---|---|
| Nominal frequency | 48 Hz ... 63 Hz |
| Rated insulation voltage | 300 V |
| Output Fuse | 5 A (fast-blow) |
| Connection Method | Screw connection |
Phoenix 8mm Stripping Length Timer Relay ETD-SL-2T-I, 2866174 Technical Specifications:
| Specification | Value |
|---|---|
| Product type | Timer relay |
| Mechanical service life | approx. 2x 107 cycles |
| Service life electrical | approx. 2x 105 cycles at ohmic load, 1000 VA |
| Nominal frequency | 48 Hz ... 63 Hz |
| Nominal power consumption | 2.5 VA (1 W) |
| Test voltage relay winding/relay contact | 4 kV |
| Rated insulation voltage | 300 V |
| Rated surge voltage | |
| Input voltage range | 24 V DC ... 240 V DC -20 % ... +25 % |
| Temperature coefficient, typical | ≤ 0.01 %/K |
| Recovery time | 500 ms |
| Setting range time | 50 ms ... 100 h (7 time end ranges) |
| Basic accuracy | ± 1 % (of scale end value) |
| Setting accuracy | ≤ 5 % (of scale end value) |
| Repeat accuracy | ≤ 0.5 % ±5 ms |
| Maximum switching voltage | 250 V AC (in acc. with IEC 60664-1) |
| Interrupting rating (ohmic load) max. | 750 VA (3 A/250 V AC, module aligned, ≤ 5 mm spacing) |
| Output fuse | 5 A (fast-blow) |
| Connection method | Screw connection |
| Stripping length | 8 mm |
| Conductor cross section rigid | 0.5 mm² ... 2.5 mm² |
| Status display | Green LED (POWER) |
| Degree of protection (Housing) | IP40 (Housing) |
| Ambient temperature (operation) | -25 °C ... 55 °C |
Call us for Phoenix 8mm Stripping Length Timer Relay ETD-SL-2T-I part no: 2866174 at the best rates. Technical Attributes of ETD-SL-2T-I, 2866174 are Timer relay boasts an impressive mechanical service life of approximately approx. 2x 107 cycles ensuring long-term reliability. With a rated insulation voltage of 300 V it supports a wide input voltage range of 24 V DC ... 240 V DC -20 % ... +25 %. The relay features a quick recovery time of over 500 ms and a versatile setting range time from 50 ms ... 100 h (7 time end ranges) different time ranges. For safety, it includes a 5 A (fast-blow) output fuse. The relay is connected via a secure Screw connection with a stripping length of 8 mm for easy installation. Unlock Exclusive Pricing with a Quote for your requirement of Phoenix 8mm Stripping Length Timer Relay. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
