PLC-TR-1T-MUL-300M-PT: 2910141 - Phoenix Contact Relay 24VDC
Technical Specifications of Phoenix Contact Relay 24VDC PLC-TR-1T-MUL-300M-PT 2910141:
| Spec | Value |
|---|---|
| Nominal frequency | |
| Rated insulation voltage | 300 V AC |
| Output Fuse | 6.3 A (fast-blow) |
| Connection Method | Push-in connection |
Phoenix Contact Relay 24VDC PLC-TR-1T-MUL-300M-PT, 2910141 Technical Specifications:
| Specification | Value |
|---|---|
| Product type | Timer relay |
| Mechanical service life | 2 x 107 cycles |
| Service life electrical | 2x 105 cycles |
| Nominal frequency | |
| Nominal power consumption | 0.45 W (at 24 V DC) |
| Test voltage relay winding/relay contact | |
| Rated insulation voltage | 300 V AC |
| Rated surge voltage | 6 kV |
| Input voltage range | 24 V DC (19.2 V DC ... 30 V DC) |
| Temperature coefficient, typical | |
| Recovery time | 50 ms |
| Setting range time | 0.1 s ... 300 min. (4 time end ranges) |
| Basic accuracy | |
| Setting accuracy | ≤ 2.5 % (of scale end value) |
| Repeat accuracy | ≤ 0.5 % (of scale end value) |
| Maximum switching voltage | 250 V AC |
| Interrupting rating (ohmic load) max. | 1500 VA (6 A / 250 V AC) |
| Output fuse | 6.3 A (fast-blow) |
| Connection method | Push-in connection |
| Stripping length | 8 mm |
| Conductor cross section rigid | 0.14 mm² ... 2.5 mm² |
| Status display | Green LED (POWER) |
| Degree of protection (Housing) | |
| Ambient temperature (operation) | -20 °C ... 65 °C |
Obtain a Quote for Phoenix Contact Relay 24VDC PLC-TR-1T-MUL-300M-PT part no: 2910141 at economical prices. Specifications Overview for PLC-TR-1T-MUL-300M-PT, 2910141 reveals Timer relay boasts an impressive mechanical service life of approximately 2 x 107 cycles ensuring long-term reliability. With a rated insulation voltage of 300 V AC it supports a wide input voltage range of 24 V DC (19.2 V DC ... 30 V DC). The relay features a quick recovery time of over 50 ms and a versatile setting range time from 0.1 s ... 300 min. (4 time end ranges) different time ranges. For safety, it includes a 6.3 A (fast-blow) output fuse. The relay is connected via a secure Push-in connection with a stripping length of 8 mm for easy installation. Take the First Step with a Quote for your requirement of Phoenix Contact Relay 24VDC. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
