FL SWITCH 1000N-8POE: 1343031 - Phoenix Contact PoE+ Ethernet Switch
Technical Specifications of Phoenix Contact PoE+ Ethernet Switch FL SWITCH 1000N-8POE 1343031:
| Spec | Value |
|---|---|
| Mounting type | DIN rail mounting |
| Connection method | Push-in spring connection |
| No. of channels | 8 (RJ45 ports) |
| Status display | LEDs: US, link and activity per port |
FL SWITCH 1000N-8POE: 1343031 - Phoenix Contact PoE+ Ethernet Switch
| Specification | Value |
|---|---|
| Width | 40 mm |
| Height | 140.4 mm |
| Depth | 92.4 mm |
| Housing material | Polycarbonate fiber reinforced |
| Mounting type | DIN rail mounting |
| Connection method | Push-in spring connection |
| Transmission speed | 10/100 Mbps |
| Transmission length | 100 m (Between transmitter / receiver) |
| Signal LEDs | LNK/ACT, POE |
| No. of channels | 8 (RJ45 ports) |
| Product type | Switch |
| MTTF | 58 Years (MIL-HDBK-217F standard, temperature 25°C, operating cycle 100%) |
| Supply voltage (DC) | 24 V |
| Supply voltage range | 20 V DC ... 57 V DC |
| Power supply connection | Via COMBICON, max. conductor cross section 2.5 mm² |
| Max. current consumption | 7 A (at 20 V DC) |
| Typical current consumption | 95 mA (at 24 V DC) |
| Degree of protection | IP30 |
| Ambient temperature (operation) | -10 °C ... 60 °C |
| Ambient temperature (storage/transport) | -40 °C ... 85 °C |
| Permissible humidity (operation) | 5 % ... 95 % (non-condensing) |
| Permissible humidity (storage/transport) | 5 % ... 95 % (non-condensing) |
| Electromagnetic compatibility | Conformance with EMC Directive 2014/30/EU |
| Noise emission | EN 61000-6-4:2007 + A1:2011 |
| Status display | LEDs: US, link and activity per port |
| Shock (operation) | 30g (EN 60068-2-27) |
| Vibration (operation) | in acc. with IEC 60068-2-6: 5g, 150 Hz |
Mail Us for your needs in Phoenix Contact PoE+ Ethernet Switch FL SWITCH 1000N-8POE part no: 1343031 with budget-friendly prices. The Main Technical Parameters of FL SWITCH 1000N-8POE, 1343031 inludce Polycarbonate fiber reinforced housing material, ensuring long-lasting performance in demanding environments. It supports easy installation with a standard DIN rail mounting making it ideal for streamlined setup in control panels. The connection method is via reliable Push-in spring connection, providing secure and stable connectivity. With a transmission speed of 10/100 Mbps it ensures fast and efficient data communication across networks. The relay supports a transmission length of up to 100 m (Between transmitter / receiver) making it versatile for various industrial settings. It features 8 (RJ45 ports). Customize Your Experience with a Quote for your requirement of Phoenix Contact PoE+ Ethernet Switch. Experience the difference with our competitive pricing and superior support over other Suppliers.
