FL SWITCH 2216: 2702904 - Phoenix 16 RJ45 ports Managed Switch
Technical Specifications of Phoenix 16 RJ45 ports Managed Switch FL SWITCH 2216 2702904:
| Spec | Value |
|---|---|
| Mounting type | DIN rail mounting |
| Connection method | Push-in spring connection |
| No. of channels | 16 (RJ45 ports) |
| Status display | LEDs: US1, US2 (power supply), Fail (alarm contact), 2 LEDs per Ethernet port (Link/Activity and Speed) |
FL SWITCH 2216: 2702904 - Phoenix 16 RJ45 ports Managed Switch
| Specification | Value |
|---|---|
| Width | 85 mm |
| Height | 130 mm |
| Depth | 119 mm |
| Housing material | Polycarbonate fiber reinforced |
| Mounting type | DIN rail mounting |
| Connection method | Push-in spring connection |
| Transmission speed | 10/100 Mbps |
| Transmission length | 100 m (per segment) |
| Signal LEDs | Data receive, link status |
| No. of channels | 16 (RJ45 ports) |
| Product type | Switch |
| MTTF | 365.63 Years (SN 29500 standard, temperature 25°C, operating cycle 21%) |
| Article revision | 4 |
| Supply voltage (DC) | 24 V DC (redundant) |
| Supply voltage range | 12 V DC ... 57 V DC |
| Power supply connection | via COMBICON, max. conductor cross section 1.5 mm² |
| Max. current consumption | 1.4 A (US = Min, Tamb = Max, DOI = Max) |
| Typical current consumption | 315 mA (at US = 24 V DC and 25 °C ambient temperature) |
| Degree of protection | IP20 |
| Ambient temperature (operation) | -40 °C ... 70 °C |
| Ambient temperature (storage/transport) | -40 °C ... 85 °C |
| Permissible humidity (operation) | 10 % ... 95 % (non-condensing) |
| Permissible humidity (storage/transport) | 10 % ... 95 % (non-condensing) |
| Electromagnetic compatibility | Conformance with EMC Directive 2014/30/EU |
| Noise emission | EN 61000-6-4 |
| Status display | LEDs: US1, US2 (power supply), Fail (alarm contact), 2 LEDs per Ethernet port (Link/Activity and Speed) |
| Shock (operation) | 30g (EN 60068-2-27) |
| Vibration (operation) | in acc. with IEC 60068-2-6: 5g, 150 Hz |
Mail Us for Phoenix 16 RJ45 ports Managed Switch FL SWITCH 2216 part no: 2702904 at the lowest pricing. Technical Specs Summary of FL SWITCH 2216, 2702904 are Polycarbonate fiber reinforced housing material, ensuring long-lasting performance in demanding environments. It supports easy installation with a standard DIN rail mounting making it ideal for streamlined setup in control panels. The connection method is via reliable Push-in spring connection, providing secure and stable connectivity. With a transmission speed of 10/100 Mbps it ensures fast and efficient data communication across networks. The relay supports a transmission length of up to 100 m (per segment) making it versatile for various industrial settings. It features 16 (RJ45 ports). Navigate Your Needs with a Quote for your requirement of Phoenix 16 RJ45 ports Managed Switch. We excel in offering more cost-effective and supportive solutions than other Competitors.
