OPT-24DC/230AC/ 1: 2967950 -Phoenix 253V Output Mini Solid-state Relay
Technical Specifications of Phoenix 253 V AC Output Miniature Solid-state Relay OPT-24DC/230AC/ 1 2967950:
| Spec | Value |
|---|---|
| Product type | Single solid-state relay |
| Insulation | Basic insulation |
| Input voltage range | 24 V DC |
| Typical input current at UN | 6.6 mA |
Phoenix 253 V AC Output Miniature Solid-state Relay OPT-24DC/230AC/ 1, 2967950 Technical Specifications:
| Specification | Value |
|---|---|
| Product type | Single solid-state relay |
| Insulation | Basic insulation |
| Overvoltage category | III |
| Maximum power dissipation for nominal condition | 0.07 W |
| Test voltage (Input/output) | 2.5 kV (50 Hz, 1 min., input/output) |
| Nominal input voltage UN | 24 V DC |
| Input voltage range in reference to UN | 0.8 ... 1.2 |
| Input voltage range | 19.2 V DC ... 28.8 V DC |
| Typical input current at UN | 6.6 mA |
| Typical response time | 10 ms (at UN) |
| Typical turn-off time | 10 ms (at UN) |
| Transmission frequency | 10 Hz |
| Contact switching type | 1 N/O contact |
| Design of digital output | electronic |
| Output voltage range | 24 V AC ... 253 V AC |
| Limiting continuous current | 0.75 A (see derating curve) |
| Maximum inrush current | 30 A (10 ms) |
| Voltage drop at max. limiting continuous current | < 1 V |
| Output circuit | 2-conductor floating, zero voltage switch |
| Protective circuit | RCV circuit; RCV circuit |
| Width | 5 mm |
| Height | 28 mm |
| Depth | 15 mm |
| Color | black (RAL 9005) |
| Degree of protection | RT III |
| Ambient temperature (operation) | -25 °C ... 60 °C |
| Ambient temperature (storage/transport) | -25 °C ... 70 °C |
| Identification | ISA-S71.04. G3 Harsh Group |
| Standards/regulations | IEC 60664 |
| Mounting position | any |
| Rated insulation voltage | |
| Output nominal voltage | |
| Min. load current | 10 mA |
| Leakage current | < 1 mA |
| Surge current | |
| Max. load value | 4.5 A2s |
| Surge voltage protection | |
| Phase angle cos phi min | 0.5 |
| Rated surge voltage |
Get A Quote for Phoenix 253 V AC Output Miniature Solid-state Relay OPT-24DC/230AC/ 1 part no: 2967950 at the best price. Here are the brief Technical Specifications of OPT-24DC/230AC/ 1, 2967950 are Product type Single solid-state relay for efficient and reliable performance. This sensor is equipped with Basic insulation ensuring safety and durability in various industrial applications. The maximum power dissipation for nominal conditions is 0.07 W making it energy-efficient. It operates at a nominal input voltage of 24 V DC with an input voltage range from 19.2 V DC ... 28.8 V DC providing flexibility for different setups. The typical input current at UN is 6.6 mA and it utilizes a 1 N/O contact switching type. The output voltage range is 24 V AC ... 253 V AC with a limiting continuous current of 0.75 A (see derating curve). The voltage drop at maximum limiting continuous current is kept minimal at < 1 V ensuring stable operation. The output circuit is a 2-conductor floating, zero voltage switch floating design. It's Time to get a Quote for your requirement of Phoenix 253 V AC Output Miniature Solid-state Relay. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
