QUINT4-PS/1AC/2X15DC/2/PT: 2904596 - Phoenix 15 VDC Power Supply
Technical Specifications of Phoenix 15 VDC Power Supply QUINT4-PS/1AC/2X15DC/2/PT 2904596:
| Spec | Value |
|---|---|
| Nominal input voltage range | |
| Nominal output voltage | ± 15 V DC |
| Nominal output current (IN) | 2 A (+) |
| Mounting Type | DIN rail mounting |
Phoenix 15 VDC Power Supply QUINT4-PS/1AC/2X15DC/2/PT, 2904596 Technical Specifications:
| Specification | Value |
|---|---|
| Nominal input voltage range | |
| Input voltage range | 110 V DC ... 250 V DC -20 % ... +10 % |
| Inrush current | < 15 A (at 25 °C) |
| Frequency range (fN) | 50 Hz ... 60 Hz -10 % ... +10 % |
| Efficiency | typ. 88.8 % (120 V AC) |
| Nominal output voltage | ± 15 V DC |
| Nominal output current (IN) | 2 A (+) |
| Residual ripple | < 60 mVPP (with nominal values) |
| Short-circuit-proof | yes |
| Power loss nominal load max. | < 6.6 W (120 V AC) |
| Insulation voltage input/output | 4 kV AC (type test) |
| Mounting type | DIN rail mounting |
| Degree of protection | IP20 |
| Ambient temperature (operation) | -25 °C ... 70 °C (> 60 °C Derating: 2,5 %/K) |
| EMC requirements for noise emission | |
| EMC requirements for noise immunity |
Talk to Our Engineer for Phoenix 15 VDC Power Supply QUINT4-PS/1AC/2X15DC/2/PT part no: 2904596 with exclusive offers. Core System Specifications of QUINT4-PS/1AC/2X15DC/2/PT, 2904596 are Operating within an input voltage range of 110 V DC ... 250 V DC -20 % ... +10 % this sensor ensures versatile power compatibility. It features a typical inrush current of < 15 A (at 25 °C) optimizing startup performance. With an impressive efficiency of approximately typ. 88.8 % (120 V AC) the sensor provides energy-efficient operation. The nominal output voltage is ± 15 V DC with a robust output current of 2 A (+) making it ideal for industrial applications. The residual ripple is kept under 60 °C Derating: 2,5 %/K). Don't Miss Out on a Quote for your requirement of Phoenix 15 VDC Power Supply. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
