ADMIRAL AX 3B LR WT: 1134604 - Reer Prewired With 10 m Lead Cable
Technical Specifications of Reer Prewired With 10 m Lead Cable ADMIRAL AX 3B LR WT 1134604:
| Spec | Value |
|---|---|
| Safety Level | Type 4 - PL e |
| Number of Beams | 3 |
| Connections | - |
| Detection | Access control |
Reer Prewired With 10 m Lead Cable ADMIRAL AX 3B LR WT 1134604 Technical Specifications:
| Specification | Value |
|---|---|
| Safety level | Type 4 - PL e |
| Protected height (mm) | 800 |
| Resolution (mm) | Multi-beams |
| Max. range (m) | 50 |
| Restart | Built-in - User selectable automatic or manual |
| Functioning system | Emitter / Receiver |
| Safety level (SIL / PL) | Type 4 - SILCL 3 - PL e - Cat. 4 |
| Operating temperature (°C) | 0 ... 55 |
| Response time (ms) | 6 |
| Number of beams | 3 |
| Max. length of the connection cables (m) | 100 |
| Signalling | 7 segment display and LEDs for light curtain's status and diagnostics |
| Safety output type | 2 fail-safe PNP (500 mA at 24 VDC) with protection against short circuit. overload and reverse polarity |
| Connections | - |
| MTTFD (ISO13849) years | 100 |
| PFHD (IEC 61508) | 9.15E-09 |
| Safety outputs | 2 OSSD PNP (500 mA at 24 VDC) |
| Safety functions | Integrated |
| Detection | Access control |
| Protective enclosures | Harsh working environments |
| Packaging dimensions HxLxW (mm) | 145 x 1260 x 200 |
| Product class | C |
| Custom tariff | 85365019 |
| Power supply (VDC) | 24 ± 20% |
| Overall height (mm) | 1141 |
| Cross section dimensions (mm) | - |
| Degree of protection | IP67 |
| Fastening Gross weight (g) | Set of 4 WFB ring brackets (included) |
| Gross weight (g) | 8500 |
| Operating Range (m) | - |
| Connector | - |
| Blanking function | - |
Mail Us for your needs in Reer Prewired With 10 m Lead Cable ADMIRAL AX 3B LR WT part no: 1134604 with budget-friendly prices. The Main Technical Parameters of ADMIRAL AX 3B LR WT, 1134604 inludce Type 4 - PL e safety level with a protected height of 800 and a resolution of Multi-beams. It utilizes 3 beams for accurate finger detection and is housed in protective enclosures for industrial applications. The compact packaging dimensions are 145 x 1260 x 200, making it suitable for various environments. The sensor operates on a 24 ± 20% power supply with, ensuring reliable performance. The overall height of the unit is 1141. Designed with an IP67 degree of protection. Customize Your Experience with a Quote for your requirement of Reer Prewired With 10 m Lead Cable. Experience the difference with our competitive pricing and superior support over other Suppliers.
