EOS2 453 A: 1320202 - Reer 460 mm Height Safety Light Curtains
Technical Specifications of Reer 460 mm Height Safety Light Curtains EOS2 453 A 1320202:
| Spec | Value |
|---|---|
| Safety level | Type 2 - PL c |
| Protected height (mm) | 460 |
| Number of Beams | 23 |
| Connections | M12 5-pole connectors |
Reer 460 mm Height Safety Light Curtains: EOS2 453 A - 1320202
| Specification | Value |
|---|---|
| Safety level | Type 2 - PL c |
| Protected height (mm) | 460 |
| Resolution (mm) | 30 |
| Controlled height (mm) | 450 |
| Max. range (m) | 12 |
| Restart | Automatic |
| Functioning system | Emitter / Receiver |
| Safety level (SIL / PL) | Type 2 - SIL 1 - SILCL 1 - PL c - Cat. 2 |
| Operating temperature (°C) | - 30 ... 55 |
| Response time (ms) | 8 |
| Number of beams | 23 |
| Max. length of the connection cables (m) | 100 (50 between Master and Slave) |
| Signalling | LEDs for light curtain's status and diagnostics |
| Safety output type | 2 fail-safe PNP (400 mA at 24 VDC) with protection against short circuit. overload and reverse polarity |
| Connections | M12 5-pole connectors |
| MTTFD (ISO13849) years | 315.6 |
| PFHD (IEC 61508) | 3.31E-08 |
| Safety outputs | 2 OSSD PNP (400 mA at 24 VDC) |
| Safety functions | With external module |
| Detection | Hand |
| Protective enclosures | None |
| Packaging dimensions HxLxW (mm) | 145 x 540 x 200 |
| Product class | C |
| Custom tariff | 85365019 |
| Power supply (VDC) | 24 ± 20% |
| Overall height (mm) | 513 |
| Cross section dimensions (mm) | 28 x 30 |
| Degree of protection | IP65 - IP67 |
| Fastening | Back slot with set of LE type brackets (included) or to the top and lower end with swivel brackets SFB E (optional) |
| Gross weight (g) | 1826.96 |
| Operating Range (m) | |
| Master Slave Models | |
| Special versions | |
| Materials suitable for food applications | |
| Light curtain technical data | |
| Diameter (mm) | |
| Max. water pressure (bar) |
Mail Us for your needs in Reer 460 mm Height Safety Light Curtains EOS2 453 A part no: 1320202 with budget-friendly prices. The Main Technical Parameters of EOS2 453 A, 1320202 include Reer Safety Light Curtains with a safety level of Type 2 - PL c, providing robust protection in industrial environments. The curtains feature a protected height of 160 and a resolution of 30, with a controlled height of 450 and a maximum range of 12. Operating within a temperature range of - 30 ... 55, these curtains have a response time of 8 and utilize an emitter/receiver system. Equipped with 2 fail-safe PNP (400 mA at 24 VDC) with protection against short circuit. overload and reverse polarity and M12 5-pole connectors, the system ensures reliable performance. The curtains include LEDs for light curtain's status and diagnostics, and the degree of protection is rated at IP65 - IP67 .Customize Your Experience with a Quote for your requirement of Reer 460 mm Height Safety Light Curtains. Experience the difference with our competitive pricing and superior support over other Suppliers.
