EOS4 1501 X WTF: 1110039 - Reer 1687 mm Height Safety Light Curtains
Technical Specifications of Reer 1687 mm Height Safety Light Curtains EOS4 1501 X WTF 1110039:
| Spec | Value |
|---|---|
| Safety Level | Type 4 - PL e |
| Protected Height (mm) | 1510 |
| Number of beams | 150 |
| Connections | Cable output |
Reer 1687 mm Height Safety Light Curtains: EOS4 1501 X WTF - 1110039
| Specification | Value |
|---|---|
| Safety Level | Type 4 - PL e |
| Protected Height (mm) | 1510 |
| Resolution (mm) | 14 |
| Controlled Height (mm) | 1500 |
| Max. Range (m) | 5 |
| Restart | Built-in - User selectable automatic or manual |
| Functioning System | Emitter / Receiver |
| Safety Level (SIL / PL) | Type 4 - SIL 3 - SILCL 3 - PL e - Cat. 4 |
| Operating Temperature (°C) | 0 ... 55 |
| Response Time (ms) | 4 |
| Number of Beams | 150 |
| Max. Length of the Connection Cables (m) | 100 |
| Signalling | LEDs for light curtain's status and diagnostics |
| Safety Output Type | 2 fail-safe PNP (400 mA at 24 VDC) with protection against short circuit. overload and reverse polarity |
| Connections | Cable output |
| MTTFD (ISO13849) years | 100 |
| PFHD (IEC 61508) | 3.22E-08 |
| Safety Outputs | 2 OSSD PNP (400 mA at 24 VDC) |
| Safety Functions | Integrated |
| Detection | Finger |
| Protective Enclosures | Food industry IP69K |
| Packaging Dimensions HxLxW (mm) | 145 x 1810 x 200 |
| Product Class | C |
| Power Supply (VDC) | 24 ± 20% |
| Overall Height (mm) | 1687 |
| Degree of Protection | IP69K |
| Fastening | Set of 4 ring brackets (included) |
| Special versions | Food and beverage. Watertight enclosure |
| Materials suitable for food applications | Yes |
| Diameter (mm) | 56 |
| Max. water pressure (bar) | 80 . . . 100 |
| Gross Weight (g) | 7983.7 |
Send Your Inquiry for Reer 1687 mm Height Safety Light Curtains EOS4 1501 X WTF part no: 1110039 with cost-effective solutions. Essential Technical Specs of EOS4 1501 X WTF, 1110039 are 1510 protected height and a 14 resolution, ensuring precise detection. It operates at a 4 response time with a 5 range. The Emitter / Receiver pair meets Type 4 - SIL 3 - SILCL 3 - PL e - Cat. 4 standards, with an operating temperature range of 0 ... 55. It includes LEDs for light curtain's status and diagnostics and uses Cable output. The device is IP69K rated for durability, with an overall length of 100. It has 2 fail-safe PNP (400 mA at 24 VDC) with protection against short circuit. overload and reverse polarity, and ensuring precise Finger, detection. With IP69K, protection and flexible mounting options, it's designed for versatile use in industrial applications. Capture the Best Deal with a Quote for your requirement of Reer 1687 mm Height Safety Light Curtains. Our pricing and support are designed to exceed the standards of other Traders & Suppliers.
