SR ONE M: 1330904 - Reer Safety Removable Terminal Block Safety Relays
Technical Specifications of Reer Safety Removable Terminal Block Safety Relays SR ONE M 1330904:
| Spec | Value |
|---|---|
| Safety Level | Type 4 - PL e |
| Safety relay outputs | 2 NO (6A at 250 VAC) |
| Connections | Removable terminal blocks. screw contacts |
| Dimensions HxWxD (mm) | 99 x 35 x 114 |
Reer Safety Removable Terminal Block Safety Relays SR ONE M, 1330904 Technical Specifications:
| Specification | Value |
|---|---|
| Safety level | Type 4 - PL e |
| Safety level (SIL / PL) | Type 4 - SILCL 3 - PL e - Cat. 4 |
| Operating temperature (°C) | - 30 ... 55 |
| Response time (ms) | ≤ 20 |
| Signalling | LEDs indication of power on. connected light curtains status. Muting status. Override status and fault diagnosis |
| Connections | Removable terminal blocks. screw contacts |
| MTTFD (ISO13849) years | The values depend on the type of use. Refer to the technical manual |
| PFHD (IEC 61508) | The values depend on the type of use. Refer to the technical manual |
| Safety devices to be connected | OSSD outpt devices. Safety light curtains: EOS4 A. EOS2 A. Admiral AD. Admiral AX BK. Vision V. Safety switches: Magnus RFID. Safety laser scanner: UAM |
| Safety relay outputs | 2 NO (6A at 250 VAC) |
| Product class | C |
| Power supply (VDC) | 24 ± 20% |
| Dimensions HxWxD (mm) | 99 x 35 x 114 |
| Degree of protection | IP2X |
| Fastening | 35 mm DIN rail fastening according to EN 50022-35 standard |
| Packaging dimensions HxLxW (mm) | 57 x 158 x 134 |
| Custom tariff | 85365080 |
| Gross weight (g) | 258.5 |
| Start/Restart | Automatic/Manual monitored selectable |
| Muting logic | L (One way) logic with 2 sensors - Crossed beams |
| Muting timeout | Selectable: 30 sec. or infinite |
| Muting inputs | 2 at 24 VDC - PNP or relay - dark on |
Send Your Inquiry for Reer Safety Removable Terminal Block Safety Relays SR ONE M part no: 1330904 with cost-effective solutions. Essential Technical Specs of SR ONE M, 1330904 are These interfaces meet Type 4 - SILCL 3 - PL e - Cat. 4 standards, ensuring top-tier protection. Operating in temperatures from - 30 ... 55, they feature a response time of ≤ 20. The interfaces include LEDs indication of power on. connected light curtains status. Muting status. Override status and fault diagnosis and use Removable terminal blocks. screw contacts. They are compatible with OSSD outpt devices. Safety light curtains: EOS4 A. EOS2 A. Admiral AD. Admiral AX BK. Vision V. Safety switches: Magnus RFID. Safety laser scanner: UAM The safety relay outputs are configured as 2 NO (6A at 250 VAC). Designed for reliability, the interfaces are mounted on a 35 mm DIN rail fastening according to EN 50022-35 standard. With dimensions of 99 x 35 x 114, they operate at 24 ± 20% and offer IP2X protection. Capture the Best Deal with a Quote for your requirement of Reer Safety Removable Terminal Block Safety Relays. Our pricing and support are designed to exceed the standards of other Traders & Suppliers.
