SR TC: 1330810 - Reer 2 NO Class C Safety Relays
Technical Specifications of Reer 2 NO Class C Safety Relays SR TC 1330810:
| Spec | Value |
|---|---|
| Safety Level | PL e |
| Safety relay outputs | 2 NO (6A at 250 VAC) |
| Connections | Removable terminal blocks. clamp contacts |
| Dimensions HxWxD (mm) | 99 x 22.5 x 114.5 |
Reer 2 NO Class C Safety Relays SR TC, 1330810 Technical Specifications:
| Specification | Value |
|---|---|
| Safety level | PL e |
| Safety level (SIL / PL) | PL e - SIL 3 - SILCL 3 - Cat. 4 - Type III C (EN 574) |
| Operating temperature (°C) | -30 ... +55 |
| Response time (ms) | ≤ 20 |
| Signalling | LEDs indication for status and diagnostic: power supply. channel 1 and channel 2 |
| Connections | Removable terminal blocks. clamp contacts |
| MTTFD (ISO13849) years | The values depend on the type of use. Refer to the technical manual |
| PFHD (IEC 61508) | The values depend on the type of use. Refer to the technical manual |
| Safety devices to be connected | Two hands control safety devices |
| Safety relay outputs | 2 NO (6A at 250 VAC) |
| Product class | C |
| Power supply (VDC) | 24 ± 20% |
| Dimensions HxWxD (mm) | 99 x 22.5 x 114.5 |
| Degree of protection | IP2X |
| Fastening | 35 mm DIN rail fastening according to EN 50022-35 standard |
| Min. switching current at 24 VDC (mA) | 6 |
| Simultaneity (s) | ≤ 0.5 |
Talk to Our Engineer for Reer 2 NO Class C Safety Relays SR TC part no: 1330810 with exclusive offers. Core System Specifications of SR TC, 1330810 are These interfaces meet PL e - SIL 3 - SILCL 3 - Cat. 4 - Type III C (EN 574) standards, ensuring top-tier protection. Operating in temperatures from -30 ... +55, they feature a response time of ≤ 20. The interfaces include LEDs indication for status and diagnostic: power supply. channel 1 and channel 2 and use Removable terminal blocks. clamp contacts. They are compatible with Two hands control safety devices The safety relay outputs are configured as 2 NO (6A at 250 VAC). Designed for reliability, the interfaces are mounted on a 35 mm DIN rail fastening according to EN 50022-35 standard. With dimensions of 99 x 22.5 x 114.5, they operate at 24 ± 20% and offer IP2X protection. Don't Miss Out on a Quote for your requirement of Reer 2 NO Class C Safety Relays. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
