SR X: 1201710 - Reer Type 2 PL c Safety Level Safety Relay
Technical Specifications of Reer Type 2 PL c Safety Level Safety Relay SR X 1201710:
| Spec | Value |
|---|---|
| Safety Level | Type 2 - PL c |
| Safety relay outputs | 2 NO (6A at 250 VAC) |
| Connections | Removable terminal blocks. screw contacts |
| Dimensions HxWxD (mm) | 99 x 22.5 x 114.5 |
Reer Type 2 PL c Safety Level Safety Relay SR X, 1201710 Technical Specifications:
| Specification | Value |
|---|---|
| Safety level | Type 2 - PL c |
| Safety level (SIL / PL) | Type 2 - SILCL 1 - PL c - Cat. 2 |
| Operating temperature (°C) | - 30 ... 55 |
| Response time (ms) | ≤ 20 |
| Signalling | LEDs indication of power on. connected photocells status and fault diagnosis |
| Connections | Removable terminal blocks. screw contacts |
| MTTFD (ISO13849) years | The values depend on the type of use. Refer to the technical manual |
| PFHD (IEC 61508) | The values depend on the type of use. Refer to the technical manual |
| Safety devices to be connected | Ilion and Ulisse safety photocell |
| Safety relay outputs | 2 NO (6A at 250 VAC) |
| Product class | C |
| Power supply (VDC) | 24 ± 20% |
| Dimensions HxWxD (mm) | 99 x 22.5 x 114.5 |
| Degree of protection | IP2X |
| Fastening | 35 mm DIN rail fastening according to EN 50022-35 standard |
| Packaging dimensions HxLxW (mm) | 57 x 158 x 134 |
| Custom tariff | 85365080 |
| Gross weight (g) | 186.8 |
| Start/Restart | Automatic/Manual monitored selectable |
Give Us a Call for Reer Type 2 PL c Safety Level Safety Relay SR X part no: 1201710 at the lowest pricing. In-depth Technical Analysis of SR X, 1201710 feature interfaces meet Type 2 - SILCL 1 - PL c - Cat. 2 standards, ensuring top-tier protection. Operating in temperatures from - 30 ... 55, they feature a response time of ≤ 20. The interfaces include LEDs indication of power on. connected photocells status and fault diagnosis and use Removable terminal blocks. screw contacts. They are compatible with Ilion and Ulisse safety photocell The safety relay outputs are configured as 2 NO (6A at 250 VAC). Designed for reliability, the interfaces are mounted on a 35 mm DIN rail fastening according to EN 50022-35 standard. With dimensions of 99 x 22.5 x 114.5, they operate at 24 ± 20% and offer IP2X protection. Elevate Your Project with a Quote for your requirement of Reer Type 2 PL c Safety Level Safety Relay. Our promise: More affordable pricing and more personalized support than other Distributors & Dealers.
