SR ZERO: 1330801 - Reed Safety Relay Modules for Safety Light Curtains
Technical Specifications of Reed Safety Relay Modules for Safety Light Curtains SR ZERO 1330801:
| Spec | Value |
|---|---|
| Safety Level | PL e |
| Safety relay outputs | 2 NO + 1 NC (6A at 250 VAC) |
| Connections | Removable terminal blocks. screw contacts |
| Dimensions HxWxD (mm) | 99 x 22.5 x 114.5 |
Reed Safety Relay Modules for Safety Light Curtains SR ZERO, 1330801 Technical Specifications:
| Specification | Value |
|---|---|
| Safety level | PL e |
| Safety level (SIL / PL) | PL e - Cat. 4 |
| Operating temperature (°C) | - 30 ... 55 |
| Response time (ms) | ≤ 20 |
| Signalling | LEDs indication for input status |
| Connections | Removable terminal blocks. screw contacts |
| MTTFD (ISO13849) years | The values depend on the type of use. Refer to the technical manual |
| PFHD (IEC 61508) | The values depend on the type of use. Refer to the technical manual |
| Safety devices to be connected | Safety devices with feedback input for external relay monitor (EDM). such us EOS4 X . EOS2 X. Admiral AX. Vision VX/VXL/MXL and Janus |
| Safety relay outputs | 2 NO + 1 NC (6A at 250 VAC) |
| Product class | C |
| Power supply (VDC) | 24 ± 20% |
| Dimensions HxWxD (mm) | 99 x 22.5 x 114.5 |
| Degree of protection | IP2X |
| Fastening | 35 mm DIN rail fastening according to EN 50022-35 standard |
Get A Quote for Reed Safety Relay Modules for Safety Light Curtains SR ZERO part no: 1330801 at the best price. Here are the brief Technical Specifications of SR ZERO, 1330801 are These interfaces meet PL e - Cat. 4 standards, ensuring top-tier protection. Operating in temperatures from - 30 ... 55, they feature a response time of ≤ 20. The interfaces include LEDs indication for input status and use Removable terminal blocks. screw contacts. They are compatible with Safety devices with feedback input for external relay monitor (EDM). such us EOS4 X . EOS2 X. Admiral AX. Vision VX/VXL/MXL and Janus The safety relay outputs are configured as 2 NO + 1 NC (6A at 250 VAC). Designed for reliability, the interfaces are mounted on a 35 mm DIN rail fastening according to EN 50022-35 standard. With dimensions of 99 x 22.5 x 114.5, they operate at 24 ± 20% and offer IP2Xprotection. It's Time to get a Quote for your requirement of Reed Safety Relay Modules for Safety Light Curtains. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
