SV MR0: 1100078 - Reer Safety Relays to connect PNP Proximity
Technical Specifications of Reer Safety Relays to connect PNP Proximity SV MR0 1100078:
| Spec | Value |
|---|---|
| Safety Level | PL e |
| Safety relay outputs | 2 NO (6A at 250 VAC) |
| Connections | Removable terminal blocks. screw contacts |
| Dimensions HxWxD (mm) | 108 x 22.5 x 114.5 |
Reer Safety Relays to connect PNP Proximity SV MR0, 1100078 Technical Specifications:
| Specification | Value |
|---|---|
| Safety level | PL e |
| Safety level (SIL / PL) | SIL 3 - SILCL 3 - PL e - Cat. 4 |
| Operating temperature (°C) | - 40 ... 55 |
| Signalling | LEDs indication for operating status and fault diagnosis |
| Connections | Removable terminal blocks. screw contacts |
| Safety devices to be connected | PNP proximities |
| Safety relay outputs | 2 NO (6A at 250 VAC) |
| Product class | C |
| Power supply (VDC) | 24 ± 20% |
| Dimensions HxWxD (mm) | 108 x 22.5 x 114.5 |
| Degree of protection | IP20 for housing - IP2X for terminal block |
| Fastening | 35 mm DIN rail fastening according to EN 50022-35 standard |
| Packaging dimensions HxLxW (mm) | 57 x 158 x 134 |
| Custom tariff | 85365080 |
| Gross weight (g) | 230.8 |
| Proximity connections | Terminal blocks |
| Max. number of proximity | 2 |
| Max. number of axes | 2 |
| Max. proximity frequency (KHz) | 5 |
Ask for the Pricing of Reer Safety Relays to connect PNP Proximity SV MR0 part no: 1100078 at unbeatable prices. Detailed Specifications of SV MR0, 1100078 feature These interfaces meet SIL 3 - SILCL 3 - PL e - Cat. 4 standards, ensuring top-tier protection. Operating in temperatures from - 40 ... 55, they feature a response time of . The interfaces include LEDs indication for operating status and fault diagnosis and use Removable terminal blocks. screw contacts. They are compatible with PNP proximities The safety relay outputs are configured as 2 NO (6A at 250 VAC). Designed for reliability, the interfaces are mounted on a 35 mm DIN rail fastening according to EN 50022-35 standard. With dimensions of 108 x 22.5 x 114.5, they operate at 24 ± 20% and offer IP20 for housing - IP2X for terminal block protection. Now's the Time to Secure a Quote for your requirement of Reer Safety Relays to connect PNP Proximity. We're committed to offering more favorable pricing and more responsive support than other Traders.
