BN 32-01: 101057229 - Schmersal Lateral Panel Magnetic Sensor
Technical Specifications of Schmersal BN 32-01 101057229:
| Spec | Value |
|---|---|
| Switching Distance Sn | BP 10 = 5 mm |
| Termination | Flat plug-in connector 4.8 mm |
| Switching Element | Opener (NC) |
| Degree of Protection | IP67 |
Schmersal Lateral Panel Magnetic Sensor, BN 32-01, 101057229 Technical Specifications:
| Specification | Value |
|---|---|
| Working principle | Magnetic drive |
| Housing construction form | Block |
| Housing material | Glass-fibre, reinforced thermoplastic |
| Active area | lateral |
| Actuating panels | lateral |
| Actuating element | Magnet |
| Actuating speed, maximum | 18 m/s |
| Switching distance Sn | BP 10 = 5 mm |
| Repeat accuracy R | 0.3 mm |
| Termination | Flat plug-in connector 4.8 mm |
| Length of sensor | 24 mm |
| Width of sensor | 85 mm |
| Height of sensor | 26 mm |
| Degree of protection | IP67 |
| Ambient temperature | -25 ... +90 °C |
| Resistant to vibration | 15 g, on sine wave oscillation |
| Switching voltage, maximum | 250 VAC |
| Switching current, maximum | 3 A |
| Switching capacity, maximum | 120 VA |
| Switching element | Opener (NC) |
| Bounce duration, minimum | 0.3 ms |
| Bounce duration, maximum | 0.6 ms |
| Maximum switching frequency | 1,080,000 /h |
| Design of control elements | Reed contacts |
| Gross weight | 58 g |
Call us for Lateral Panel Magnetic Sensor BN 32-01 part no: 101057229 at the best rates. Technical Attributes of BN 32-01, 101057229 are Magnetic drive working principle. The sensor features a Block housing construction form, made from Glass-fibre, reinforced thermoplastic ensuring durability and resistance to harsh environments. It has a switching distance (Sn) of BP 10 = 5 mm making it ideal for precise applications. The sensor is equipped with a Flat plug-in connector 4.8 mm for secure and easy termination. It supports a maximum switching voltage of 250 VAC and a switching current of up to 3 A providing robust performance in various industrial settings. The switching element is an Opener (NC) which ensures reliable operation when the circuit needs to be closed upon activation. With an IP67 rating, the sensor is fully protected against dust and water ingress, making it suitable for both indoor and outdoor applications. The gross weight of the sensor is 58 g. Unlock Exclusive Pricing with a Quote for your requirement of Lateral Panel Magnetic Sensor. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
