BNS 333-01YL-M20: 101169805 - Schmersal Thermoplastic Magnetic Safety Sensors
Technical Specifications of Schmersal Thermoplastic Magnetic Safety Sensors BNS 333-01YL-M20 101169805:
| Spec | Value |
|---|---|
| Working principle | Magnetic drive |
| Connector position | - |
| Termination | Screw terminals M20 x 1.5 |
| Degree of protection | IP65 |
Schmersal Thermoplastic Magnetic Safety Sensors, BNS 333-01YL-M20, 101169805 Technical Specifications:
| Specification | Value |
|---|---|
| Working principle | Magnetic drive |
| Installation conditions (mechanical) | quasi-flush |
| Housing material | Glass-fibre, reinforced thermoplastic |
| Number of normally closed (NC) | 1 |
| Number of normally open (NO) | - |
| Active area | left-hand side |
| Actuating element | Magnet |
| Direction of motion | Head-on to the active surface |
| Assured switching distance "ON" Sao | 4 mm |
| Assured switching distance "OFF" Sar | 14 mm |
| Connector position | - |
| Termination | Screw terminals M20 x 1.5 |
| Length of sensor | 39 mm |
| Width of sensor | 52 mm |
| Height of sensor | 90 mm |
| Degree of protection | IP65 |
| Ambient temperature | -25 ... +55 °C |
| Storage and transport temperature | -25 ... +70 °C |
| Resistance to vibrations | 10 … 55 Hz, amplitude 1 mm |
| Restistance to shock | 30 g / 11 ms |
| Switching voltage, maximum | 250 VAC |
| Switching current, maximum | 5 A |
| Switching capacity, maximum | 1,250 W |
| Switching element | 1 NC contact |
| Switching frequency, maximum | 5 Hz |
| Design of control elements | - |
| Gross weight | 150 g |
Obtain a Quote for Schmersal Thermoplastic Magnetic Safety Sensors BNS 333-01YL-M20 part no: 101169805 at economical prices. Specifications Overview for BNS 333-01YL-M20, 101169805 reveals Magnetic drive Working principle, featuring a durable Glass-fibre, reinforced thermoplastic housing. The sensor operates with a Magnet actuating element, ensuring reliable performance. It provides an assured switching distance (Sao) of 4 mm and an (Sar) distance of 14 mm making it ideal for precise applications. Termination is facilitated through an Screw terminals M20 x 1.5 ensuring secure and efficient connections. The sensor supports a maximum switching voltage of 250 VAC and a maximum switching current of 5 A. It includes both 1 NC contact for versatile operation, with a switching frequency of up to 5 Hz. Rated with an IP65 degree of protection. Take the First Step with a Quote for your requirement of Schmersal Thermoplastic Magnetic Safety Sensors. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
