CSS 11-30S-D-M-ST: 101204612 - Schmersal 2 LEDs Electronic Safety Sensors
Technical Specifications of Schmersal 2 LEDs Electronic Safety Sensors CSS 11-30S-D-M-ST 101204612:
| Spec | Value |
|---|---|
| Working principle | inductive |
| PFH value | 3.60 x 10⁻⁹ /h |
| - | - |
| Degree of protection | IP65, IP67 |
Schmersal 2 LEDs Electronic Safety Sensors , CSS 11-30S-D-M-ST, 101204612 Technical Specifications:
| Specification | Value |
|---|---|
| Working principle | inductive |
| Housing construction form | Cylinder, thread |
| Installation conditions (mechanical) | not flush |
| Sensor topology | Sensor for series wiring |
| Housing material | Stainless steel |
| Active area | front side |
| Reaction time, maximum | 60 ms |
| Duration of risk, maximum | 60 ms |
| Number of LEDs | 2 |
| Number of fail-safe digital outputs | 2 |
| Number of series-wiring of sensors | 31 |
| PFH value | 3.60 x 10⁻⁹ /h |
| Actuating panels | Actuation from top |
| Hysteresis (Switching distance), maximum | 2 mm |
| Repeat accuracy R | 1 mm |
| Termination | - |
| Wire cross-section | - |
| Length of sensor | 99.5 mm |
| Width of sensor | - |
| Height of sensor | - |
| Degree of protection | IP65, IP67 |
| Ambient temperature | -25 ... +65 °C |
| Storage and transport temperature | -25 ... +85 °C |
| Resistance to vibrations | 10 … 55 Hz, amplitude 1 mm |
| Restistance to shock | 30 g / 11 ms |
| Protection class | II |
| Rated insulation voltage Ui | 32 VAC/DC |
| Rated impulse withstand voltage Uimp | 0.8 kV |
| Operating current | 600 mA |
| Required rated short-circuit current | 100 A |
| Switching frequency, approx. | 3 Hz |
| Rated operating current (safety outputs) | 250 mA |
| Output current, (fail-safe output), maximum | 0.25 A |
| Design of control elements | p-type |
| Voltage drop Ud, maximum | 5 V |
| Gross weight | 245 g |
Ask for the Pricing of Schmersal 2 LEDs Electronic Safety Sensors CSS 11-30S-D-M-ST part no: 101204612 at unbeatable prices. Detailed Specifications of CSS 11-30S-D-M-ST, 101204612 feature Cylinder, thread construction form with a durable Stainless steel housing. This sensor ensures reliable performance with a PFH value of 3.60 x 10⁻⁹ /hper hour. The Actuation from top providing consistent and precise operation. Termination is facilitated via a - ensuring secure and easy connections. The sensor has a rated insulation voltage (Ui) of 32 VAC/DC and supports an operating current of up to 600 mA. With an approximate switching frequency of 3 Hz this sensor is designed to meet the rigorous demands of industrial applications. Its dual degree of protection, rated at IP65, IP67. Now's the Time to Secure a Quote for your requirement of Schmersal 2 LEDs Electronic Safety Sensors . We're committed to offering more favorable pricing and more responsive support than other Traders.
