EX-AZM 415-02/02ZPK 24VAC/DC-3D: 101188673 - Schmersal Aluminium Solenoid Interlock
Technical Specifications of Schmersal Aluminium Solenoid Interlock EX-AZM 415-02/02ZPK 24VAC/DC-3D 101188673:
Spec | Value |
---|---|
Working Principle | electromechanical |
Mounting | - |
Termination | Screw terminals M20 x 1.5 |
Switching Element | NO contact, NC contact |
Schmersal Aluminium Solenoid Interlock, EX-AZM 415-02/02ZPK 24VAC/DC-3D, 101188673 Technical Specifications:
Specification | Value |
---|---|
Working principle | electromechanical |
Housing material | Aluminium |
Number of safety contacts | 4 |
Impact energy, maximum | 4 J |
Energy impact (protective case), maximum | - |
Holding force | 3,500 N |
Latching force | 80 N-400 N |
Positive break travel | 5 mm |
Positive break force, minimum | 15 N |
Actuating speed, maximum | 1 m/s |
Mounting | - |
Type of the fixing screws | - |
Type of the screw head | - |
Tightening torque of the fastening screws for the housing cover, minimum | - |
Tightening torque of the fastening screws for the housing cover, maximum | - |
Tightening torque of the cable gland | - |
Termination | Screw terminals M20 x 1.5 |
Cable cross-section of the cable glands, minimum | 7 mm |
Cable cross-section of the cable glands, maximum | 12 mm |
Cable section, minimum | 0.75 mm² |
Cable section, maximum | 2.5 mm² |
Length of sensor | 46.5 mm |
Width of sensor | 130 mm |
Height of sensor | 100 mm |
Degree of protection | IP67 |
Ambient temperature | -10 ... +50 °C |
Electrical power consumption, maximum | 10 W |
Switching element | NO contact, NC contact |
Switching principle | Slow action |
Maximum switching frequency | - |
Material of the contacts, electrical | Silver |
Gross weight | 910 g |
Ask for the Pricing of Schmersal Aluminium Solenoid Interlock EX-AZM 415-02/02ZPK 24VAC/DC-3D part no: 101188673 at unbeatable prices. Detailed Specifications of EX-AZM 415-02/02ZPK 24VAC/DC-3D, 101188673 feature electromechanical Working principle, designed with a housing made of Aluminium. The device features a latching force of 80 N-400 N ensuring secure and reliable operation in hazardous environments. It is mounted using - and utilizes the Screw terminals M20 x 1.5. The cable section ranges from 0.75 mm² to 2.5 mm² accommodating various installation needs. The sensor consumes a maximum of 10 W of electrical power, with an NO contact, NC contact switching element and a Slow action switching principle. It supports a maximum switching frequency of - making it suitable for demanding industrial applications. The device is rated IP67. Now's the Time to Secure a Quote for your requirement of Schmersal Aluminium Solenoid Interlock. We're committed to offering more favorable pricing and more responsive support than other Traders.
