ZQ 700-11: 131192476 - Schmersal Emergency Stop Trip Wire Switches
Technical Specifications of Schmersal Emergency Stop Trip Wire Switches ZQ 700-11 131192476:
| Spec | Value |
|---|---|
| Length of the wire, maximum | 10 m |
| Termination | Screw terminals M20 x 1.5 |
| Switching Element | NO contact, NC contact |
| Degree of Protection | IP66, IP67 |
Schmersal Emergency Stop Trip Wire Switches ZQ 700-11, 131192476 Technical Specifications:
| Specification | Value |
|---|---|
| Housing material | Glass-fibre, thermoplastic |
| Housing coating material | - |
| Length of the wire, maximum | 10 m |
| Actuation direction | - |
| Positive break force, minimum | - |
| Tightening torque of the fixing screws | - |
| Tightening torque of the fastening screws for the housing cover | - |
| Termination | Screw terminals M20 x 1.5 |
| Cable section, minimum | 0.75 mm² |
| Cable section, maximum | 2.5 mm² |
| Tightening torque of electrical connection, minimum | - |
| Tightening torque of electrical connection, maximum | - |
| Length | - |
| Width | 40.5 mm |
| Height | 160 mm |
| Width of the actuator | - |
| Height of the actuator | - |
| Degree of protection | IP66, IP67 |
| Ambient temperature | -25 ... +70 °C |
| Thermal test current | 10 A |
| Required rated short-circuit current | - |
| Switching element | NO contact, NC contact |
| Material of the contacts, electrical | Silver |
| Gross Weight | 215 g |
Talk to Our Engineer for Schmersal Emergency Stop Trip Wire Switches ZQ 700-11 part no: 131192476 with exclusive offers. Core System Specifications of ZQ 700-11, 131192476 are Glass-fibre, thermoplastic for enhanced durability. The sensors support a maximum wire length of 10 m and use Screw terminals M20 x 1.5 termination. The cable section ranges from a minimum of 0.75 mm² to a maximum of 2.5 mm² ensuring flexibility in installation. The designed for compact spaces. Rated IP66, IP67, these sensors offer high protection against dust and water ingress, making them suitable for harsh environments. They operate reliably in ambient temperatures from -25 ... +70 °C The switching element includes NO contact, NC contact with Silver electrical contacts for optimal conductivity. Don't Miss Out on a Quote for your requirement of Schmersal Emergency Stop Trip Wire Switches. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
