ZQ215AR-02: 103044935 - Schmersal M20 Screw Terminals Stop Switches
Technical Specifications of Schmersal M20 Screw Terminals Stop Switches ZQ215AR-02 103044935:
| Spec | Value |
|---|---|
| Length of the wire, maximum | 25 m |
| Termination | Screw terminals M20 x 1.5 |
| Switching Element | 2 NC contact |
| Degree of Protection | IP66, IP67 |
Schmersal M20 Screw Terminals Stop Switches ZQ215AR-02, 103044935 Technical Specifications:
| Specification | Value |
|---|---|
| Housing material | Metal, zinc die-cast |
| Housing coating material | painted |
| Length of the wire, maximum | 25 m |
| Actuation direction | right |
| Positive break force, minimum | 40 N |
| Tightening torque of the fixing screws | 2 Nm |
| Tightening torque of the fastening screws for the housing cover | 2.6 Nm |
| Termination | Screw terminals M20 x 1.5 |
| Cable section, minimum | 0.34 mm² |
| Cable section, maximum | 1.5 mm² |
| Tightening torque of electrical connection, minimum | 0.6 Nm |
| Tightening torque of electrical connection, maximum | 0.8 Nm |
| Length | 32.4 mm |
| Width | 31 mm |
| Height | 93.4 mm |
| Width of the actuator | 91 mm |
| Height of the actuator | 21.4 mm |
| Degree of protection | IP66, IP67 |
| Ambient temperature | -30 ... +80 °C |
| Thermal test current | 10 A |
| Required rated short-circuit current | 400 A |
| Switching element | 2 NC contact |
| Material of the contacts, electrical | Silver |
| Gross Weight | 342 g |
Call us for Schmersal M20 Screw Terminals Stop Switches ZQ215AR-02 part no: 103044935 at the best rates. Technical Attributes of ZQ215AR-02, 103044935 are Metal, zinc die-cast for enhanced durability. The sensors support a maximum wire length of 25 m and use Screw terminals M20 x 1.5 termination. The cable section ranges from a minimum of 0.34 mm² to a maximum of 1.5 mm² ensuring flexibility in installation. The actuator has a width of 91 mm and a height of 21.4 mm, designed for compact spaces. Rated IP66, IP67, these sensors offer high protection against dust and water ingress, making them suitable for harsh environments. They operate reliably in ambient temperatures from -30 ... +80 °C The switching element includes 2 NC contact with Silver electrical contacts for optimal conductivity. Unlock Exclusive Pricing with a Quote for your requirement of Schmersal M20 Screw Terminals Stop Switches. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
