ATV310H075N4E: Schneider 1 HP VFD
Technical Specifications of Schneider 1 HP VFD ATV310H075N4E:
| Spec | Value |
|---|---|
| Minimum switching current | 5 mA at 24 V DC for logic relay |
| Output voltage | 380...460 V three phase |
| Switching frequency | 2...12 kHz adjustable |
| Nominal switching frequency | 4 kHz |
Schneider 1 HP VFD ATV310H075N4E Technical Specifications:
| Specification | Value |
|---|---|
| Minimum switching current | 5 mA at 24 V DC for logic relay |
| Analogue output number | 1 |
| Height | 143 mm |
| Speed drive output frequency | 0.5…400 Hz |
| Unit Type of Package 2 | S06 |
| Time constant | 20 ms +/- 1 ms for reference change |
| Operating altitude | <= 1000 m without derating |
| Number of addresses | 1…247 for Modbus |
| Supply frequency | 50/60 Hz +/- 5 % |
| Device short name | ATV310 |
| Acceleration and deceleration ramps | Linear from 0...999.9 sSU |
| Speed range | 1…20 for asynchronous motor |
| Physical interface | 2-wire RS 485 for Modbus |
| Product or component type | Variable speed drive |
| Ambient air temperature for storage | -25…70 °C |
| Analogue input number | 1 |
| Output voltage | 380...460 V three phase |
| Continuous output current | 2.3 A heavy duty |
| Package 2 Weight | 50.95 kg |
| Asynchronous motor control profile | Voltage/frequency ratio (V/f)Voltage/frequency ratio - Energy Saving, quadratic U/fSensorless vector control (SVC) |
| Electrical connection | Terminal, clamping capacity: 1.5...2.5 mm², AWG 16...AWG 14 (L1, L2, L3, U, V, W) |
| Maximum switching current | 2 A at 250 V AC on inductive load cos phi = 0.4 L/R = 7 ms for logic relay2 A at 30 V DC on inductive load cos phi = 0.4 L/R = 7 ms for logic relay3 A at 250 V AC on resistive load cos phi = 1 L/R = 0 ms for logic relay4 A at 30 V DC on resistive load cos phi = 1 L/R = 0 ms for logic relay |
| Electromagnetic compatibility | Electrical fast transient/burst immunity test - test level: level 4 conforming to IEC 61000-4-4Electrostatic discharge immunity test - test level: level 3 conforming to IEC 61000-4-2Immunity to conducted disturbances - test level: level 3 conforming to IEC 61000-4-6Radiated radio-frequency electromagnetic field immunity test - test level: level 3 conforming to IEC 61000-4-3Voltage dips and interruptions immunity test conforming to IEC 61000-4-11Surge immunity test - test level: level 3 conforming to IEC 61000-4-5 |
| Motor slip compensation | Adjustable |
| Supply | Internal supply for reference potentiometer: 5 V (4.75…5.25 V)DC, <10 mA with overload and short-circuit protectionInternal supply for logic inputs: 24 V (20.4…28.8 V)DC, <100 mA with overload and short-circuit protection |
| Braking torque | Up to 70 % of nominal motor torque without braking resistor |
| Number of Units in Package 1 | 1 |
| Width | 72 mm |
| Package 1 Weight | 1.06 kg |
| Range of product | Easy Altivar 310 |
| Depth | 140 mm |
| Operating position | Vertical +/- 10 degree |
| Pollution degree | 2 conforming to IEC 61800-5-1 |
| Communication service | Read holding registers (03) 29 wordsWrite single register (06) 29 wordsWrite multiple registers (16) 27 wordsRead/write multiple registers (23) 4/4 wordsRead device identification (43) |
| Quantity per set | Set of 1 |
Request a quote for the Schneider 1 HP VFD ATV310H075N4E at the best price. This model features a minimum switching current of 5 mA at 24 V DC for logic relay control and supports a speed drive output frequency range of 0.5…400 Hz, offering flexibility for diverse industrial applications. The response time for reference changes is 20 ms +/- 1 ms, and it operates on a supply frequency of 50/60 Hz with a +/- 5 % tolerance. Designed for a speed range of 1…20 for asynchronous motors, it includes a 2-wire RS 485 interface for Modbus communication. The VFD operates on an output voltage of 380...460 V in a three-phase configuration and provides a continuous output current of 2.3 A for heavy-duty use. The adjustable switching frequency ranges from 2...12 kHz, with a nominal frequency of 4 kHz, and it features an RJ45 connector on the front for easy Modbus access. Contact us for a customized quote on the Schneider 1 HP VFD and experience our competitive pricing and exceptional support that surpasses other distributors.
