LC1E06004F7IN: Schneider Easy TeSys 32A 110V AC 4P Contactor
Technical Specifications of Schneider Easy TeSys 32A 110V AC 4P Contactor LC1E06004F7IN:
| Spec | Value |
|---|---|
| Product Component Type | Contactor |
| [Ue] rated operational voltage | Power circuit: <= 690 V AC 50/60 Hz |
| Power Dissipation Per Pole | 0.09 W AC-31 W AC-1 |
| Tightening Torque | Power circuit: 1.2 N.mControl circuit: 1.2 N.m |
Schneider Easy TeSys 32A 110V AC 4P Contactor LC1E06004F7IN Technical Specifications:
| Specification | Value |
|---|---|
| Range | Easy TeSys |
| Range of product | Easy TeSys Control |
| Product or component type | Contactor |
| Poles description | 4P |
| [Ue] rated operational voltage | Power circuit: <= 690 V AC 50/60 Hz |
| [Ie] rated operational current | 20 A (at <40 °C) at <= 415 V AC AC-1 for power circuit |
| [Uc] control circuit voltage | 110 V AC 50/60 Hz |
| Pole contact composition | 4 NO |
| [Ith] conventional free air thermal current | 20 A (at 40 °C) for power circuit |
| Irms rated making capacity | 60 A at 440 V AC for power circuit conforming to IEC 60947-4-1 |
| Rated breaking capacity | 48 A at 440 V for power circuit conforming to IEC 60947 |
| [Icw] rated short-time withstand current | 80 A 40 °C - 10 s for power circuit45 A 40 °C - 60 s for power circuit20 A 40 °C - 600 s for power circuit |
| Associated fuse rating | 10 A gG at <= 690 V coordination type 1 for control circuit conforming to IEC 60947-5-112 A gG at <= 690 V coordination type 1 for power circuit |
| Power dissipation per pole | 0.09 W AC-31 W AC-1 |
| [Ui] rated insulation voltage | 690 V conforming to IEC 60947-4-1 |
| [Uimp] rated impulse withstand voltage | 6 kV conforming to IEC 60947 |
| Control circuit type | AC at 50/60 Hz |
| Control circuit voltage limits | 0.85...1.1 Uc (-5…55 °C):operational 50/60 Hz0.3...0.6 Uc (-5…55 °C):drop-out 50/60 Hz |
| Inrush power in VA | 95 VA 50 Hz cos phi 0.75 (at 20 °C)95 VA 60 Hz cos phi 0.75 (at 20 °C) |
| Hold-in power consumption in VA | 8.5 VA 50 Hz cos phi 0.3 (at 20 °C)8.5 VA 60 Hz cos phi 0.3 (at 20 °C) |
| Heat dissipation | 2…3 W for control circuit |
| Operating time | 12...22 ms on closing4...19 ms on opening |
| Maximum operating rate | 1800 cyc/h 60 °C |
| Connections - terminals | Power circuit: screw clamp terminals 1 1…4 mm² - cable stiffness: flexible with cable endPower circuit: screw clamp terminals 2 1…2.5 mm² - cable stiffness: flexible with cable endPower circuit: screw clamp terminals 1 1…6 mm² - cable stiffness: solid without cable endPower circuit: screw clamp terminals 2 1…4 mm² - cable stiffness: solid without cable endControl circuit: screw clamp terminals 1 1…4 mm² - cable stiffness: flexible without cable endControl circuit: screw clamp terminals 2 1…4 mm² - cable stiffness: flexible without cable endControl circuit: screw clamp terminals 1 1…4 mm² - cable stiffness: flexible with cable endControl circuit: screw clamp terminals 2 1…2.5 mm² - cable stiffness: flexible with cable endControl circuit: screw clamp terminals 1 1…6 mm² - cable stiffness: solid without cable endControl circuit: screw clamp terminals 2 1…4 mm² - cable stiffness: solid without cable end |
| Tightening torque | Power circuit: 1.2 N.mControl circuit: 1.2 N.m |
| Minimum switching voltage | 17 V for control circuit |
| Minimum switching current | 5 mA for control circuit |
| Mounting support | DIN railPlate |
| IP degree of protection | IP2X conforming to IEC 60529 |
| Height | 74 mm |
| Width | 45 mm |
| Depth | 80 mm |
| Net weight | 0.34 kg |
Call us for Schneider Easy TeSys 32A 110V AC 4P Contactor LC1E06004F7IN at the best rates. Technical Attributes of LC1E06004F7IN are Easy TeSys Control Range of products and the Contactor Product or component type 4P, designed for efficient performance in Power circuit: <= 690 V AC 50/60 Hz. This product features a rated operational current of 20 A (at <40 °C) at <= 415 V AC AC-1 for power circuit. It operates at a control circuit voltage of 110 V AC 50/60 Hz, with 4 NO poles. The conventional free air thermal current is rated at 20 A (at 40 °C) for power circuit, and power dissipation per pole is 0.09 W AC-31 W AC-1. The rated insulation voltage is 690 V conforming to IEC 60947-4-1, and the impulse withstand voltage is 6 kV conforming to IEC 60947. Unlock Exclusive Pricing with a Quote for your requirement of Schneider Easy TeSys 32A 110V AC 4P Contactor. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
