TM241CE40T: Schneider M241 Controller 40 IO Transistor PNP Ethernet
Tecnhical specifications of Schneider M241 Controller 40 IO Transistor PNP Ethernet TM241CE40T fzo9$9h6a356v:
Spec | Value |
---|---|
Standards | ANSI/ISA 12-12-01CSA C22.2 No 142CSA C22.2 No 213IEC 61131-2:2007Marine specification (LR, ABS, DNV, GL)UL 508 |
Supply voltage limits | 20.4…28.8 V |
IP degree of protection | IP20 with protective cover in place |
Power consumption in W | 32.6…40.4 W (with max number of I/O expansion module) |
Ambient air temperature for operation | -10…50 °C (vertical installation)-10…55 °C (horizontal installation) |
Schneider M241 Controller 40 IO Transistor PNP Ethernet TM241CE40T Technical Specifications:
Specification | Value |
---|---|
Insulation | Between supply and internal logic at 500 V ACNon-insulated between supply and groundBetween input and internal logic at 500 V ACNon-insulated between inputsBetween fast input and internal logic at 500 V ACBetween output and internal logic at 500 V ACNon-insulated between outputsBetween fast output and internal logic at 500 V ACBetween output groups at 500 V AC |
Power consumption in W | 32.6…40.4 W (with max number of I/O expansion module) |
Port Ethernet | 10BASE-T/100BASE-TX - 1 port(s) copper cable |
Output voltage limits | 30 V DC |
Transmission rate | 1.2...115.2 kbit/s (115.2 kbit/s by default) for bus length of 15 m for RS4851.2...115.2 kbit/s (115.2 kbit/s by default) for bus length of 3 m for RS232480 Mbit/s for bus length of 3 m for USB10/100 Mbit/s for Ethernet |
Voltage state 0 guaranteed | <= 5 V for input |
Range of product | Modicon M241 |
Maximum output frequency | 20 kHz for fast output (PWM mode)100 kHz for fast output (PLS mode)1 kHz for output |
Discrete output current | 0.1 A for fast output (PTO mode) (Q0...Q3)0.5 A for transistor output (Q0...Q15) |
Response time | <= 2 µs turn-on, I0...I7 terminal(s) for fast input<= 2 µs turn-off, I0...I7 terminal(s) for fast input<= 2 µs turn-on, Q0...Q3 terminal(s) for fast output<= 2 µs turn-off, Q0...Q3 terminal(s) for fast output50 µs turn-on, I0...I15 terminal(s) for input50 µs turn-off, I0...I15 terminal(s) for input<= 34 µs turn-on, Q0...Q15 terminal(s) for output<= 250 µs turn-off, Q0...Q15 terminal(s) for output |
Surge withstand | 1 kV power lines (DC) common mode conforming to IEC 61000-4-51 kV shielded cable common mode conforming to IEC 61000-4-50.5 kV power lines (DC) differential mode conforming to IEC 61000-4-51 kV relay output differential mode conforming to IEC 61000-4-51 kV input common mode conforming to IEC 61000-4-51 kV transistor output common mode conforming to IEC 61000-4-5 |
Shock resistance | 15 gn for 11 ms |
Protection type | Short-circuit protectionShort-circuit and overload protection with automatic resetReverse polarity protection for fast output |
Supply voltage limits | 20.4…28.8 V |
Communication port protocol | Non isolated serial link: Modbus master/slave |
Vibration resistance | 3.5 mm at 5…8.4 Hz on symmetrical rail3 gn at 8.4…150 Hz on symmetrical rail3.5 mm at 5…8.4 Hz on panel mounting3 gn at 8.4…150 Hz on panel mounting |
Voltage state 1 guaranteed | >= 15 V for input |
Discrete output voltage | 24 V DC for transistor output |
Standards | ANSI/ISA 12-12-01CSA C22.2 No 142CSA C22.2 No 213IEC 61131-2:2007Marine specification (LR, ABS, DNV, GL)UL 508 |
Discrete input current | 10.7 mA for fast input7 mA for input |
Relative humidity | 10…95 %, without condensation (in operation)10…95 %, without condensation (in storage) |
Ambient air temperature for operation | -10…50 °C (vertical installation)-10…55 °C (horizontal installation) |
Discrete input voltage | 24 V |
Ambient air temperature for storage | -25…70 °C |
IP degree of protection | IP20 with protective cover in place |
IndMALL Automation Dealing offers Schneider M241 Controller 40 IO Transistor PNP Ethernet TM241CE40T at unbeatable prices. The Main Technical Parameters of TM241CE40T are Modicon M241 range, designed for efficient industrial automation. The sensor supports both Sink or source discrete input logic and operates with a power consumption of 32.6…40.4 W (with max number of I/O expansion module). The output voltage limits are 30 V DC, ensuring reliable performance. With a compact depth of 95 mm, it fits seamlessly into various setups. The discrete input voltage type is DC, and the supply voltage limits range from 20.4…28.8 V, providing flexibility in power management. The sensor handles inrush currents of up to 50 A and operates at altitudes up to 0...2000 m, with a storage altitude capacity of up to 0…3000 m. It supports a discrete input voltage of 24 V and can be stored in ambient air temperatures ranging from -25…70 °C. Take the First Step with a Quote for your requirement of Schneider M241 Controller 40 IO Transistor PNP Ethernet. Choose us for unparalleled pricing and support over other Dealers & Distributors.
