TM241CEC24U: Schneider M241 Ethernet CAN Master Controller
Technical Specifications of Schneider M241 Ethernet CAN Master Controller TM241CEC24U:
| Spec | Value |
|---|---|
| Power Consumption in W | 32.6…40.4 W (with max number of I/O expansion module) |
| Discrete Output Type | Transistor |
| Discrete Input Voltage | 24 V |
| Operating Altitude | 0...2000 m |
Schneider M241 Ethernet CAN Master Controller TM241CEC24U Technical Specifications:
| Specification | Value |
|---|---|
| Storage altitude | 0…3000 m |
| Discrete input logic | Sink or source |
| Pollution degree | 2 |
| Insulation | Between supply and internal logic at 500 V ACNon-insulated between supply and groundBetween input and internal logic at 500 V ACNon-insulated between inputsBetween fast input and internal logic at 500 V ACBetween output and internal logic at 500 V ACNon-insulated between outputsBetween fast output and internal logic at 500 V AC |
| Power consumption in W | 32.6…40.4 W (with max number of I/O expansion module) |
| Output voltage limits | 30 V DC |
| Depth | 95 mm |
| Discrete input voltage type | DC |
| Maximum number of I/O expansion module | 7 (local I/O-Architecture)14 (remote I/O-Architecture) |
| Transmission rate | 1.2...115.2 kbit/s (115.2 kbit/s by default) for bus length of 15 m for RS4851.2...115.2 kbit/s (115.2 kbit/s by default) for bus length of 3 m for RS232480 Mbit/s for bus length of 3 m for USB10/100 Mbit/s for Ethernet1000 kbit/s for bus length of 20 m for CANopen800 kbit/s for bus length of 40 m for CANopen500 kbit/s for bus length of 100 m for CANopen250 kbit/s for bus length of 250 m for CANopen125 kbit/s for bus length of 500 m for CANopen50 kbit/s for bus length of 1000 m for CANopen20 kbit/s for bus length of 2500 m for CANopen |
| Range of product | Modicon M241 |
| Width | 150 mm |
| Backup time | 2 years at 25 °C |
| Reset time | 10 ms automatic reset output12 s automatic reset fast output |
| Height | 90 mm |
| Discrete output type | Transistor |
| Discrete output current | 0.5 A for transistor output (Q0...Q9)0.1 A for fast output (PTO mode) (Q0...Q3) |
| Response time | 50 µs turn-on, I0...I13 terminal(s) for input50 µs turn-off, I0...I13 terminal(s) for input<= 2 µs turn-on, I0...I7 terminal(s) for fast input<= 2 µs turn-off, I0...I7 terminal(s) for fast input<= 34 µs turn-on, Q0...Q9 terminal(s) for output<= 250 µs turn-off, Q0...Q9 terminal(s) for output<= 2 µs turn-on, Q0...Q3 terminal(s) for fast output<= 2 µs turn-off, Q0...Q3 terminal(s) for fast output |
| Discrete output number | 10 transistor 4 fast output |
| Discrete output logic | Negative logic (sink) |
| Shock resistance | 15 gn for 11 ms |
| Protection type | Short-circuit protectionShort-circuit and overload protection with automatic resetReverse polarity protection for fast output |
| Supply voltage limits | 20.4…28.8 V |
| Discrete input number | 14, discrete input 8 fast input conforming to IEC 61131-2 Type 1 |
| Communication port protocol | Non isolated serial link: Modbus master/slave |
| Inrush current | 50 A |
| Electrical connection | removable screw terminal blockfor inputs and outputs (pitch 5.08 mm) removable screw terminal blockfor connecting the 24 V DC power supply (pitch 5.08 mm) |
| Net weight | 0.53 kg |
| Operating altitude | 0...2000 m |
| Discrete input voltage | 24 V |
| Ambient air temperature for storage | -25…70 °C |
Obtain a Quote for Schneider M241 Ethernet CAN Master Controller TM241CEC24U at economical prices. Specifications Overview for TM241CEC24U reveals Modicon M241 range, designed for efficient industrial automation. The sensor supports both Sink or source discrete input logic and operates with a power consumption of 32.6…40.4 W (with max number of I/O expansion module). The output voltage limits are 30 V DC, ensuring reliable performance. With a compact depth of 95 mm, it fits seamlessly into various setups. The discrete input voltage type is DC, and the supply voltage limits range from 20.4…28.8 V, providing flexibility in power management. The sensor handles inrush currents of up to 50 A and operates at altitudes up to 0...2000 m, with a storage altitude capacity of up to 0…3000 m. It supports a discrete input voltage of 24 V and can be stored in ambient air temperatures ranging from -25…70 °C. Take the First Step with a Quote for your requirement of Schneider M241 Ethernet CAN Master Controller. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
