WFE-030040B137: 1106554 - Sick 40 mm Depth Fork Sensor
Technical Specifications of Sick 40 mm Depth Fork Sensor WFE-030040B137 1106554:
| Spec | Value |
|---|---|
| Dimensions (W x H x D) | 10 mm x 59.3 mm x 60.5 mm |
| Switching output | Push-pull: PNP/NPN |
| Switching mode | Light/dark switching |
| Connection type | Cable, open-ended, 3-wire, 2 m |
Sick 40 mm Depth Fork Sensor WFE-030040B137, 1106554 Technical Specifications:
| Specification | Value |
|---|---|
| Functional principle | Fork sensor |
| Dimensions (W x H x D) | 10 mm x 59.3 mm x 60.5 mm |
| Fork width | 30 mm |
| Fork depth | 40 mm |
| Minimum detectable object (MDO) | 0.5 mm |
| Light Source | - |
| Adjustment | Potentiometer, light/dark switching |
| Current consumption | < 30 mA 1) |
| Switching frequency | 5 kHz |
| Stability of response time | ± 20 µs |
| Switching output | Push-pull: PNP/NPN |
| Switching output (voltage) | Push-pull: PNP/NPN High = UV - < 2 V/Low: ≤ 2 V |
| Switching mode | Light/dark switching |
| Switching output hysteresis | < 0.1 mm |
| Output current Imax. | 100 mA |
| Initialization time | 100 ms |
| Connection type | Cable, open-ended, 3-wire, 2 m |
| Protection class | III |
| Circuit protection | UV connections, reverse polarity protected, Output Q short-circuit protected, Interference pulse suppression |
| Enclosure rating | IP67 |
| Housing material | Plastic, ABS, Coated carbon steel (frame) |
IndMALL Automation Dealing offers Sick 40 mm Depth Fork Sensor WFE-030040B137 part no: 1106554 at unbeatable prices. The Main Technical Parameters of WFE-030040B137, 1106554 feature Fork sensor, 10 mm x 59.3 mm x 60.5 mm dimensions, 30 mm fork width, 40 mm fork depth, 10 V DC ... 30 V DC supply voltage, < 30 mA 1) current consumption, 5 kHz frequency, ± 20 µs response time, Push-pull: PNP/NPN output, Light/dark switching, 100 mA output current, Cable, open-ended, 3-wire, 2 m, IP67 Enclosure rating. Take the First Step with a Quote for your requirement of Sick 40 mm Depth Fork Sensor. Choose us for unparalleled pricing and support over other Dealers & Distributors.
