Wenglor OCP352P0150P Photoelectric Sensor
The Wenglor OCP352P0150P Photoelectric Sensor offers 50 ... 350 mm working range, 20 ... 150 µm reproducibility maximum, Laser (red) light source , M12 × 1; 8-pin, X-cod. connection. Manufactured by Wenglor under the Wenglor Photoelectric Sensor category, this model belongs to the Wenglor laser Series.
| Brand | Wenglor |
| Product Type | Photoelectric Sensor |
| Model Number | OCP352P0150P |
Wenglor OCP352P0150P Photoelectric Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Working Range | 50 ... 350 mm |
| Reproducibility maximum | 20 ... 150 µm |
| Linearity Deviation | 100 ... 500 µm |
| Light Source | Laser (red) |
| Wavelength | 655 nm |
| Temperature Drift | < 20 µm/K |
| Temperature Range | -25 ... 50 °C |
| Setting Method | Menu (OLED) |
| Housing Material | Plastic, PMMA Zinc diecasting |
| Degree of Protection | IP68 |
| Connection | M12 × 1; 8-pin, X-cod. |
| Optic Cover | Plastic, PMMA |
| Weight | 280 g |
| Other parameters | Resolution Output rate Exposure time Filter Laser light Offset Teach-in mode |
| Measuring Range | 300 mm |
| Output rate | 330 /s |
