Wenglor OCP801H0180 Photoelectric Sensor
The Wenglor OCP801H0180 Photoelectric Sensor offers 30 ... 80 mm working range, 60 µm reproducibility maximum, 18 ... 30 V DC supply Voltage , M12 × 1; 8-pin connection. Manufactured by Wenglor under the Wenglor Photoelectric Sensor category, this model belongs to the Wenglor laser Series.
| Brand | Wenglor |
| Product Type | Photoelectric Sensor |
| Model Number | OCP801H0180 |
Wenglor OCP801H0180 Photoelectric Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Working Range | 30 ... 80 mm |
| Reproducibility maximum | 60 µm |
| Reproducibility: 1 Sigma | 20 µm |
| Linearity Deviation | 80 µm |
| Light Source | Laser (red) |
| Wavelength | 660 nm |
| Supply Voltage | 18 ... 30 V DC |
| Current Consumption (Ub = 24 V) | < 80 mA |
| Response Time | 1,000 µs |
| Temperature Drift | < 15 µm/K |
| Temperature Range | -25 ... 50 °C |
| Setting Method | Teach-In |
| Housing Material | Plastic, ABS Plastic, PC |
| Degree of Protection | IP67 |
| Connection | M12 × 1; 8-pin |
| Optic Cover | Plastic, PMMA |
| Weight | 45 g |
| Other parameters | Scale analog output Exposure time Filter Resolution mode Emitted light Speed mode |
| Measuring Range | 50 mm |
| Measuring Rate | 1,000 /s |
| Analog output | 0...10 V 4...20 mA |
