Wenglor P1PY107 Photoelectric Sensor
The Wenglor P1PY107 Photoelectric Sensor offers 0 ... 10,000 mm working range, 18 ... 30 V DC supply voltage, IP67, IP68 degree of Protection , M12 ร 1; 5-pin connection. Manufactured by Wenglor under the Wenglor Photoelectric Sensor category, this model belongs to the Wenglor laser Series.
| Brand | Wenglor |
| Product Type | Photoelectric Sensor |
| Model Number | P1PY107 |
Wenglor P1PY107 Photoelectric Sensor โ Technical Specifications
| Specification | Value |
|---|---|
| Working Range | 0 ... 10,000 mm |
| Light Source | Laser (red) |
| Wavelength | 660 nm |
| Service Life (T = +25 ยฐC) | 100,000 h |
| Laser Class (EN 60825-1) | 1 |
| Beam Divergence | < 2 mrad |
| Reflector required | no |
| Supply Voltage | 18 ... 30 V DC |
| Current Consumption (Ub = 24 V) | < 40 mA |
| Temperature Range | -40 ... 50 ยฐC |
| Housing Material | Plastic, ABS |
| Optic Cover | Plastic, PMMA |
| Degree of Protection | IP67, IP68 |
| Connection | M12 ร 1; 5-pin |
| Temperature Drift | < 0.4 mm/K |
| Output | Error Output Warning output |
| Measuring Range | 50 ... 10,000 mm |
| Measuring Rate | 100 /s* |
| Weight | 41 g |
