YP11VAH3ANZ: Wenglor Laser Light Source Color Sensor
Technical Specifications of Wenglor Laser Light Source Color Sensor YP11VAH3ANZ:
| Spec | Value |
|---|---|
| Working Range | 60 ... 100 mm |
| Light Source | Laser (red) |
| Switching Frequency | 20 kHz |
| Connection | M12 × 1; 4-pin |
Wenglor Laser Light Source Color Sensor YP11VAH3ANZ Technical Specifications:
| Specification | Value |
|---|---|
| Working Range | 60 ... 100 mm |
| Working Distance | 100 mm |
| Resolution (Gray Scale) | - |
| Switching Hysteresis | < 50 µm |
| Light Source | Laser (red) |
| Wavelength | 660 nm |
| Max. Ambient Light | 10,000 Lux |
| Light Spot Diameter | 0.8 mm |
| Supply Voltage | 10 ... 30 V DC |
| Current Consumption (Ub = 24 V) | < 30 mA |
| Switching Frequency | 20 kHz |
| Response Time | 25 µs |
| Temperature Range | -10 ... 60 °C |
| Switching Output Voltage Drop | < 2.5 V |
| Switching Output/Switching Current | 200 mA |
| Setting Method | Potentiometer |
| Housing Material | Plastic, ABS, Plastic, PBT |
| Optic Cover | Plastic, PMMA |
| Degree of Protection | IP65 |
| Connection | M12 × 1; 4-pin |
| Output | PNP NC, PNP NO |
| Weight | 110 g |
Talk to Our Engineer for Wenglor Laser Light Source Color Sensor YP11VAH3ANZ with exclusive offers. Core System Specifications of YP11VAH3ANZ, are range of 60 ... 100 mm it provides a working distance of 100 mm gray scales. With a switching hysteresis of < 50 µm, the sensor uses white light across a wavelength of 660 nm. It can handle ambient light up to 10,000 Lux and features a light spot diameter of 0.8 mm. The sensor operates on a supply voltage of 10 ... 30 V DC, consuming < 30 mA, with a switching frequency of 20 kHz and a response time of 25 µs. It functions effectively in temperatures ranging from -10 ... 60 °C, with a switching output voltage drop of < 2.5 V and a switching current of 200 mA. The device is equipped with a Potentiometer setting method, housed in durable Plastic, ABS, Plastic, PBT with a Plastic, PMMA optic cover, and offers IP65 protection. The connection is via an,M12 × 1; 4-pin with PNP NC, PNP NO outputs.It's Time to get a Quote for your requirement of Wenglor Laser Light Source Color Sensor. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
