E3FB-TN21: Omron Through-beam NPN Sensor
Technical Specifications of E3FB-TN21 Omron Through-beam NPN Sensor
| Spec | Value |
|---|---|
| Shape | Cylindrical axial |
| Sensing Method | Through-beam |
| Emitter Number | |
| Receiver Number | |
| Sensing Distance | 20m |
Omron Through-beam NPN Sensor E3FB-TN21 Technical Specifications:
| Specification | Value |
|---|---|
| Shape | Cylindrical axial |
| Sensing Method | Through-beam |
| Emitter Number | |
| Receiver Number | |
| Sensing Distance | 20m |
| Light Source Wavelength | Red LED |
| Connection Method | M12 Connector |
| Power Supply Voltage | 10 to 30 VDC |
| Output Configuration | NPN |
| Power Consumption | 40 mA max. (Emitter 25 mA max. Receiver 15 mA max.) |
| Operation Mode | Light-ON/Dark-ON |
| Thread Size | M18 |
| Length | 48mm |
| Response Time | 0.5ms |
| Degree of Protection | IP67/IP69K |
| Material Housing | Brass, nickel plated |
| Features | NA |
Please speak to our Technical Engineer for Omron Through-beam NPN Sensor E3FB-TN21 at attractive prices. Technical Specs Summary of E3FB-TN21 includes 20m length, IP67/IP69K, M12 Connector, NPN, 40 mA max(Emitter 25 mA max.Receiver 15 mA max.), Brass,nickel plated material, M18 thread size, 0.5ms response time. Match Your Needs with a Quote for your requirement of Omron Through-beam NPN Sensor. We lead with pricing that's more favorable and support that's more attentive than other Suppliers & Traders.
